30308DJ T-N Tapered Roller Bearings 30308 Bearing for Sale










Product Description





The requirements for the main spindles on modern machine tools continue to increase. For this reason, growing demands are also being made of the spindle bearings. A reliable, continuous supply of lubrication to the working surfaces of the bearing is a particular challenge; without this lubrication, bearing operation would be impossible.


Tapered roller bearings consist of four basic components including the inner ring , the outer ring, tapered rollers, and a cage (roller retainer). Tapered roller bearings are designed such that their conical rollers and raceways are arranged so that all elements of the roller and raceway cones meet at a common apex on the bearing axis. The rollers are guided by the contact between the large end of the roller and the rib on the inner ring.




























































d

40
mm
Bore diameter
D

90
mm
Outside diameter
T

25.25
mm
Total bearing width
d1


 62.55
mm
Inner ring shoulder diameter
B

23
mm
Width inner ring
C

20
mm
Width outer ring
r1,2

min.
 2
mm
Corner radius inner ring
r3,4

min.
 1.5
mm
Corner radius outer ring
a

19.031
mm
Distance pressure point
W

0.73 kg
Mass bearing




















































da

max.
 53
mm
Abutment diameter shaft
db

min.
 49.5
mm
Abutment diameter shaft
Da

min.
 77
mm
Abutment diameter housing
Da

max.
 82
mm
Abutment diameter housing
Db

min.
 82
mm
Abutment diameter housing
Ca

min.
 3
mm
Abutment housing - axial space at the large side face/ both sides of the outer ring
Cb

min.
 5
mm
Abutment housing - axial space at the small side face/ both sides of the outer ring
ra

max.
 2
mm
Fillet radius
rb

max.
 1.5
mm
Fillet radius
