Сверхмощный 3 тонн 5 мини гусеничный кран/паук кран цена на

Сверхмощный 3 тонн 5 мини гусеничный кран/паук кран цена на

Категория: Cranes >>>
Поставщик: Shandong,Hengwang,Group,Co.,Ltd.

Цена:18 500,00 $ - 21 999,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	22015.12 $*	23116.21 $*
Aug-18-2025	21830.49 $*	22922.32 $*
Jul-18-2025	18315.67 $*	19231.12 $*
Jun-18-2025	21460.13 $*	22533.7 $*
May-18-2025	18685.48 $*	19619.27 $*
Apr-18-2025	21090.10 $*	22145.34 $*
Mar-18-2025	20905.54 $*	21950.48 $*
Feb-18-2025	20720.58 $*	21756.2 $*
Jan-18-2025	20535.78 $*	21562.73 $*

Характеристики

Product Description

Narrow Space Mini spider telescopic boom mounted mobile crane Crawler Crane For Sale

Spider cranes are mainly used in narrow places where large cranes cannot be deployed. It can be driven by gasoline or 380V motor and can realize wireless remote control operation. It can be used as a small aerial work truck by installing a working gondola. Its products are widely used in the hoisting of cemetery tombstones, the installation of indoor electrical equipment in substations, the installation and maintenance of pipeline laying of equipment in petrochemical plants, the installation and maintenance of glass curtain walls, the installation and maintenance of high-rise lamps and lanterns in buildings, indoor decoration and other occasions with narrow spaces.

The spider crane can avoid the problem of hydraulic cranes occupying transportation trucks. It can move on the site by itself, and even enter a small space for indoor lifting operations, making construction more convenient and feasible. At the same time, it is equipped with wireless remote control and overload alarm. Type computer control system, sound and light alarm system and other safety devices.

Narrow Space Mini spider telescopic boom mounted mobile crane Crawler Crane For Sale

Technical Parameters

Technical Specification of 3ton mini Spider crane

Specifications			Stretch
Operating radius	2.89t within 1.3m	Boom form	：5 sections fully automatic
Maximum operating radius	8.45m	Undulation angle
Maximum ground lifting height	9.5m	Boom angle	0-75°
Winch			Rotation
Lifting speed of hook	3.6m/min(4 times）	Rotation angle	360° continuous rotation
Winch	Wire rope	Move
Diameter and length	Φ8mmX50m	Move method	Hydraulic walking
Outrigger			Walking speed	Infinitely variable speed 0-2km/h
Outrigger form	Breaststroke	Walking device	Synthetic rubber
Outrigger stretch	The first stage is automatic, the second stage is manually adjusted	Gradeability	30°
Maximum reach	The distance between the two legs is 4.04m (width) x 3.47m (length)	Ground pressure	36Kpa
Power			Fuel tank capacity
Environmental power	Single cylinder machine or three-phase motor 3KW	Hydraulic oil tank volume	30L
Dimensions
Crane shape (length x width x height)	29509501500mm
