Напольная зарядная станция KAYAL ev

Product name

EV Charging Station-AC 7KW

Model

KY-AC-7KW

Overall dimension(mm)

370*255*85

Human-computer interaction

4.3-inch display

AC power supply

220Vac±20% ; 50Hz±10% ; L+N+PE

Rated current

32A

Output power

7kW

Work environment

Altitude：≤2000m;

Charging mode

Card swiping and code scanning

Networking mode

2G、4G、Wifi、Applet

Operation mode

Offline non billing, offline billing and online billing

Protection function

Overvoltage, undervoltage, overcurrent, short circuit, surge, leakage, etc

Charging interface

GB/T 20234.2-2015

Charging line length

Standard 5m (optional)

Degree of protection

Ip54

Installation mode

Corresponding accessories are required for wall mounted or floor mounted installation

A: Alibaba online fast payment, T/T

A: All major components are tested before assembly and each charger is fully tested before shipped

A: Yes, and usually 7-10 days to production and 7-10 days to express.

A: To know how long to charge a car, you need to know the OBC(on board charger) power of the car, the car battery capacity, the charger power. The hours to fully charge a car =battery kw.h/obc or charger power the lower one. For e.g, the battery is 40kw.h, obc is 7kw, charger is 22kw, the 40/7=5.7hours. If the obc is 22kw, then 40/22=1.8hours.

A: We are professional EV charger manufacturer.
