Горячая Распродажа горизонтальный 200 кг пищевой сухой порошок ленточный Миксер для твердых
- Категория: Mixing Equipment >>>
- Поставщик: Shanghai,Yulan,Packing,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 4582.89 $* | 4811.74 $* |
| Aug-16-2025 | 4543.73 $* | 4770.41 $* |
| Jul-16-2025 | 3812.20 $* | 4003.69 $* |
| Jun-16-2025 | 4466.62 $* | 4689.5 $* |
| May-16-2025 | 3889.18 $* | 4083.4 $* |
| Apr-16-2025 | 4389.40 $* | 4608.31 $* |
| Mar-16-2025 | 4351.32 $* | 4569.43 $* |
| Feb-16-2025 | 4312.30 $* | 4528.78 $* |
| Jan-16-2025 | 4274.99 $* | 4488.14 $* |
Характеристики
Product shows
Powder Mixer / ribbon Blender / Dry Powder Mixing Machine
Products Configuration
Model | YH-100 | YH-200 | YH-300 | YH-500 | YH-1000 | YH-1500 | YH-2000 | YH-3000 | |||||||
Capacity | 100L | 200L | 300L | 500L | 1000L | 1500L | 2000L | 3000L | |||||||
Total volume | 140L | 280L | 420L | 710L | 1420L | 1800L | 2400L | 4000L | |||||||
Max loading rate | 70% | ||||||||||||||
Total power | 3KW | 4KW | 5.5KW | 7.5KW | 11KW | 15KW | 22KW | 30KW | |||||||
Weight | 200kg | 250kg | 350kg | 500kg | 700kg | 1000kg | 1300kg | 2200kg | |||||||
Length (mm) | 1100 | 1370 | 1550 | 1773 | 2394 | 2715 | 3080 | 4270 | |||||||
Width (mm) | 750 | 834 | 970 | 1100 | 1320 | 1397 | 1625 | 2200 | |||||||
Height (mm) | 1300 | 1647 | 1655 | 1855 | 2187 | 2313 | 2453 | 2400 | |||||||
Radius of barrel (mm) | 210 | 277 | 307 | 377 | 450 | 485 | 534 | 600 | |||||||
Motor speed | 46 rpm | 46 rpm | 46 rpm | 46 rpm | 36 rpm | 32 rpm | 32 rpm | 32 rpm | |||||||
Shaft diameter (mm) | 57 | 57 | 76 | 76 | 83 | 102 | 102 | 133 | |||||||
Tank body thickness(mm) | 3 | 3 | 3 | 4 | 4 | 4 | 5 | 5 | |||||||
Side body thickness(mm) | 6 | 6 | 8 | 8 | 10 | 12 | 12 | 14 | |||||||
Ribbon thickness(mm) | 6 | 6 | 6 | 6 | 8 | 10 | 10 | 10 | |||||||
No. | Name | Brand |
1 | Stainless steel | China |
2 | Circuit breaker | Schneider |
3 | Emergency switch | Schneider |
4 | Main Switch | China changxin |
5 | Contactor | Schneider |
6 | Heat relay | Schneider |
7 | Relay | Omron |
8 | Timer relay | Omron |
9 | Button | Schneider |
10 | Pneumatic parts | Taiwan Airtac |
11 | Motor and reducer | China(ZIK) |
Product Exhibition
Ribbon Mixer
l High mixing speed and short uniform time. Mixing speed is around 8-20mins.
l All stainless steel 304 material.
l Full Mirror polished mixing tank inside, as well as ribbon and shaft.
l Safety switch ,safety grid.
l Castors for easy moving.
l Discharge is Pneumatic valve control,design to guarantee no material leaking.
l All stainless steel 304 material.
l Full Mirror polished mixing tank inside, as well as ribbon and shaft.
l Safety switch ,safety grid.
l Castors for easy moving.
l Discharge is Pneumatic valve control,design to guarantee no material leaking.
New designed cover
1.SS304 air out let
2.An observation port was added to the lid
3.There is a safety grid inside the observation port
4.The main safety grid is installed inside the machine
Full welding
The whole welding place of the machine are full welding, including the ribbon, the frame, the tank, etc. Especially for the lid of
the barrel, the full welding technology makes sure there is no gap to hide material.
the barrel, the full welding technology makes sure there is no gap to hide material.
Pneumatic discharge
1.High quality Pneumatic discharge device with key on shaft, able to bear heavy material
2.Gas seal, no leakage
Double-ribbon
The outer ribbon pushes the material from the two sides to the center.
The inner ribbon pushes the material from the center to both sides
Operation panel
1.on
2.off
3.discharge
4.Time setting
5.Switch
6.Emergency stop button
CE certificate
Packing & Delivery
Packing Details : PACKAGES in Wooden box,film wrapped inside
Delivery Details : 5-7days
Delivery Details : 5-7days
Our Company
Factory
Workshop
Accessories rack
Warehouse
Office
Electrical room
For more details
Hi ,I am Darren
Email:darren(at)yulanpack.cn
Tel/whatsapp:00-86 18036202581
If you have any requirements,please let me know.
Email:darren(at)yulanpack.cn
Tel/whatsapp:00-86 18036202581
If you have any requirements,please let me know.
Payment Terms
Payment Terms | T/T | EXW | 30% T/T in advance, paid the 70% balance before shipment | ||
FOB | |||||
CFR | |||||
CIF | |||||
Paypal | Amount lower than 3000usd | ||||
West Union | Amount lower than 5000usd | ||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
Delivery Time | 7~10days after receiving payment of Deposit | ||||
After- Sales Service
Training services: | We will train your engineer to install our machine. You can send your engineer to our factory . We will introduce your engineer how to install the machine and how to fix problem. |
Trouble shooting service: | Usually we will help you solve the problem quickly. Some times if you can not fix the problem in your country, we will send our engineer there if you need us to support. Of course,you need to afford the round trip flight ticket and accommodation fee. |
Spare Parts replacement: | For machine in guarantee period, if spare part broken, we will send you the parts free and we will pay the express fee. And please send us the spare partsback. when machine is out of guarantee period, we will provide you the spare parts in cost price. |
FAQ
1.Are you a factory or a trading company?
We have two Yulan brand companies.
Shanghai Yulan is a trading company for export trade
Nantong Yulan is a factory for processing and production equipment.
Shanghai Yulan is a trading company for export trade
Nantong Yulan is a factory for processing and production equipment.
2.Can i visit your factory?
Yes,you are always welcomed.
3.What's your warrantly and after-sale service?
One year warrantly and lifelong after-sale service via skype/email/mobile/whatsapp.
4.What's the payment term?
30% T/T despoit and 70% T/T balance payment before shipping.
5.How long it takes for delivery?
It takes about 20-40 working days.
