Школьные уличные паровые ресурсы для самостоятельного вождения AGV образовательный набор научных
- Категория: >>>
- Поставщик: Guangzhou,Emulation,Robot,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 24609.61 $* | 25839.22 $* |
| Aug-18-2025 | 24402.76 $* | 25622.27 $* |
| Jul-18-2025 | 20473.19 $* | 21497.55 $* |
| Jun-18-2025 | 23989.7 $* | 25188.47 $* |
| May-18-2025 | 20887.3 $* | 21931.1 $* |
| Apr-18-2025 | 23575.82 $* | 24754.53 $* |
| Mar-18-2025 | 23368.58 $* | 24536.27 $* |
| Feb-18-2025 | 23162.18 $* | 24320.70 $* |
| Jan-18-2025 | 22955.9 $* | 24103.97 $* |
Характеристики
School Outdoor STEAM resources self driving AGV Educational kit science kit experiment kit
Standalone mobile Security guard Policemen Unmanned police vehicle AGV Outdoor patroling car robot Security monitoring Collaborative robot
Specifications:
| Specs for ROS chassis | |
| No. | EVO-0010 Evolutionary |
| Size (with anti-collision bar) (customizable): | 1096*799*346(MM) |
| battery capacity | 24V 30AH |
| Motor power (can be set | 200w*4 |
| Battery life | >3H |
| Chassis weight | 68KG |
| Maximum load | >120KG |
| Max Speed | >1M/S |
| Battery voltage | 24V/48V |
| Applicable scene | Space outside/closed group park/inside |
| way of communication | 232 serial port/CAN |
| Transmitter type | High-precision encoder (1024 lines |
| motor | Brushless servo motor |
| System Support | WIN/ROS/UBUNTU/APOLLO |
| Maximum slope (with load) | >25 |
| Minimum turning rich radius | Rotate in place |
| control precision | 1% |
| Ability (vertical ladder) | >8CM |
| Tire diameter | 320MM |
| Drive way | Four-wheel drive (differential drive) |
| Braking method | Servo judgment car (back electromotive force cutting car) |
| Operating temperature | minus 20--60 |
| Chassis optional accessories | |
| Sensor bracket | 1 set |
| Lidar | 1 set |
| touch screen | 1 set |
| Smart module | 1 set |
| GPS module | 1 set |
Applications:
| Size (with anti-control bar) | 1423*866*505(MM) | System supports | WIN/ROS/UBUNTU/APOLLO |
| Motor power (customizable) | 1000WN | minimum turning radius | 2.3M |
| Battery capacity | 48V30AH | control accuracy | given speed ±1% |
| Speed | Maximum 20KMH | Obstacle Crossing | 8-10CMVertical Platform |
| Endurance time | >3H | climbing(load) | 8-10'' |
| Maximum load (customizable) | 150KG | External power supply | 24V/12V/5V |
| Maximum travel speed | 0-20KM/H | Suspension type | Double wishbone independent suspension |
| Battery voltage | 48V | adapts to terrain | indoor and outdoor roads |
| Drive mode | Front steering (Ake quantity control by wire) | Braking mode | Motor brake (reverse electric brake)/Mechanical drum brake |
| Emergency stop button | support | Support Stationary | support |
| Wheel diameter | 360MM | semi-start | support |
| Sensor type | Angle feedback sensor | Wheelbase | 785MM |
| System communication interface | CAN communication | Vehicle material | Sheet metal/metal |
| Accessories for ET-01 series: | |||
| ET-01 series chassis | 1 set | Charger | 1 set |
| ET-1 series shell | 1 set | CAN communication module | 1 set |
| Brushless servo motor | 2 sets | Core VCU control core block | 1 set |
| Brushless Servo Actuator | 2 sets | Multifunctional power supply system | 1 set |
| lithium battery | 1 set | Selector | 1 set |
| Independent suspension | 4 sets | Angle sensor | 1 set |
| Voltmeter | 1 set | speed sensor | 1 set |
| Anti-collision bar | 1 set | Light | 3 sets |
| Optional accessories: | |||
| Unmanned industrial computer | 1 set | 116-line Lidar | 1 set |
| Single-line lidar | 1 set | RTKGPS module | 1 set |
| Small smart camera | 1 set | Trolley bracket (with touch screen) | 1 set |
