Кабель электропитания 0,75-10 мм2, Электрический кабель
US $0.45-$0.55
UL1277 мощность и контроль 8awg tc кабель огнестойкий 18awg
- Категория: Control Cables >>>
- Поставщик: Hebei,Huatong,Wires&cables,Group,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 45.48 $* | 47.14 $* |
| Aug-15-2025 | 45.0 $* | 47.6 $* |
| Jul-15-2025 | 38.14 $* | 40.97 $* |
| Jun-15-2025 | 44.64 $* | 46.81 $* |
| May-15-2025 | 38.54 $* | 40.84 $* |
| Apr-15-2025 | 43.29 $* | 45.88 $* |
| Mar-15-2025 | 43.34 $* | 45.2 $* |
| Feb-15-2025 | 43.3 $* | 45.44 $* |
| Jan-15-2025 | 42.30 $* | 44.25 $* |
Характеристики
Our Services
Advantage of our company:
1.with 28 years' production and 16 years' exporting experience, 70% cables are for exporting, annual export volume exceed USD 400million;
2. With UL, cUL, TUV, KEMA, CE, BV, PSB, SABS, LLOYD'S, DNV.GL, NK, KR, ABS.....etc Products certifications& test reports.
3. CNAS approval laboratory.
4. Strong production ability: UL listed cables, rubber cables, mining cables, MV&LV power cables, PV cables, control cables, electrical wires, marine cables, ESP cables, rolling/reeling cables, ABC cables, bare conductor, crane cable, welding cable, and many other types.
5. Professional oversea market team: most of the sales engineers are with more than 10 years' experience of cables exporting, with quick reply and correct quotation.
For saving time, pls contact us directly (7days/16hours service):
Product Description
UL1277 Power and control 8awg tc cable flame retardant 18awg 8awg tc cable flame retardant thhn
1. Application:
In free air, raceways or direct burial
In wet or dry locations
Permitted for use in Class I, Division 2 industrial hazardous locations per NEC
Permitted for Exposed Run (ER) use in accordance with NEC
2. Construction:
Conductor:
14 AWG thru 750 kcmil bare, annealed copper per ASTM B3
Class B stranding per ASTM B8
Insulation:
Flame-retardant Cross-linked Polyethylene (XLPE)
Color-coded per ICEA Method 4; individual
conductors colored black with conductor
number surface printed in contrasting ink
Ground:
Uninsulated bare annealed copper per ASTM B3
Class B stranding per ASTM B8
Jacket:
Lead-free, flame-retardant, sunlight-resistant Polyvinyl Chloride (PVC)
3. Standard:
Industry Compliances:
UL 44 Type XHHW-2, UL 1277 Type TC, TC-ER, UL 1581, ICEA S-95-658/NEMA WC70
Flame Test Compliances: UL 1581/UL 2556 VW-1
4. Features:
Rated at 90 C wet or dry
Ripcord applied to all cables with jacket thickness of 60 mils or less
Abrasion and chemical resistant
Excellent electrical properties
Sunlight and weather resistant
|
|
|
Insulation Thickness |
Min. Avg. Jacket Thickness |
NOMINAL CABLE O.D. |
||||
|
number of Cond. |
Cond. Size (AWG) |
Cond. Strand. |
Ground Wire Size (AWG) |
IN |
MM |
IN |
MM |
IN |
|
14 AWG - 750 kcmil MULTI-CONDUCTORS |
||||||||
|
3 |
14 |
7/.0242 |
14 |
0.030 |
0.76 |
0.045 |
1.14 |
0.390 |
|
3 |
12 |
7/.0305 |
12 |
0.030 |
0.76 |
0.045 |
1.14 |
0.435 |
|
3 |
10 |
7/.0385 |
10 |
0.030 |
0.76 |
0.060 |
1.52 |
0.485 |
Certification
We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS GOST and so on. We also have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,
KEMA, TUV, SABS,PBS,Bureau Veritas, Lloyd,GL,NK,KR certifications.
We have obtained UL certifications for TC cable, DLO cable,RHH/RHW/RHW-2,XHHW/XHHW-2/SIS, THHN,SER/SEU/USE, MV-90/MV-105,MC cable,AC cable,TECK 90,SOOW,Welding cable,Mining cable,type DG,PV cable,Shipboard cable and so on.
Company Information
Company name : Hebei Huatong Wires and Cables Group Co., Ltd
Establishment : 1993
Registered capital : CNY430.82 Million, equal to: US$62 Million
Plant size : 220,000SQM
Employees : 2000+
Production capacity: US$500Million
Sub-factories : in South Africa, Tanzania, Kazakhstan, Cameroon, etc.
Main products : ESP cable, mining cable, power cable up to 46KV, control cable, lift cable, shipboard cable, housing wire, and many other special cables.
Address : No.111 Huatong Avenue Fengnan Industrlal Zone Tangshan,Hebei Province, China
Packaging & Shipping
There are some different packing methods for different cables, packing length and clients' requirement, normally:
1. For small wires, housing wire, THW, THHN, etc: coils or plastic drums;
2. For the power cables less than 1Ton/drum: wooden drums;
3. For the cables weight 1Ton~4.5Ton: steel-wooden drum;
4. For >4.5Ton, pure steel drum.
