Сертификат TUV IP67 Водонепроницаемый 4 рельсов 3 диода PV/фотоэлектрической/распределительный щиток солнечной
- Категория: Solar Related Products >>>
- Поставщик: Shanghai,Sdo,Energy,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 2.29 $* | 2.92 $* |
| Aug-17-2025 | 2.25 $* | 2.62 $* |
| Jul-17-2025 | 2.91 $* | 2.17 $* |
| Jun-17-2025 | 2.30 $* | 2.20 $* |
| May-17-2025 | 2.17 $* | 2.35 $* |
| Apr-17-2025 | 2.26 $* | 2.38 $* |
| Mar-17-2025 | 2.39 $* | 2.60 $* |
| Feb-17-2025 | 2.50 $* | 2.84 $* |
| Jan-17-2025 | 2.95 $* | 2.46 $* |
Характеристики
Specification
Standard | TUV | U L | |
Overall Dimension | 90*85*15mm | 100*85*15mm | |
Rated Voltage | 1500VDC | 1500VDC | |
Rated Current | 15A | ||
Working Temperature Range | -40℃～+85℃ | -40℃～+90℃ | |
Safety Class | Class II | ||
IP Grade | IP67 | ||
Waterproof Structure | Potting sealant | ||
Volume of Potting Glue | Appr. 30ml | ||
Cable Cross Section Range | 4mm² | 12AWG | |
Width of Ribbons | Up to 8mm | ||
Connection Method of Ribbons | Soldering | ||
Center Line Spacing of Ribbons | 20mm | ||
Height of Ribbons | Appr. 15mm | ||
Contact Material | Copper, Tin-plated | ||
Insulation Material | PPO | ||
Optional Connector | MC4/PV-GZX1500 | ||
Products Description
GZX156Q
It adopts full Potting-glue, waterproof, Out-door use design with TUV approval. Which will apply to the PV module of 156*156 mm cells with 4 ribbons. Meanwhile, The junction box can reduce PV module’s power consumption and improve electrical reliability.Installation Precautions
● PV module’s ribbon alignment must be complied with JB’s mounting hole of the terminal base.
● Adhesive and sealing compound, Potting glue must be applied by using specific type and specification. Make sure JB will be fixed in the correct position and reliable sealant. The potting glue level should be over the top surface of Diodes and terminal base. In order to avoid electrical shock risk.
● Don’t move PV module or JB before adhesive and sealing compound solidify.
● Ensure soldering between Ribbons and terminal reliably in order to avoid missing soldering or false
soldering. The soldering operators must be professionally trained. More soldering time will cause the diodes damaged.
● Adopt anti-static protection measures when touch JB.
● Make sure the connection method between JB and PV module in the correct polarity.Otherwise, Wrong connection will cause fire.
● PV module manufacturer should inspect the diodes of JBs before shipment since the diodes might be damaged by heat temperature or the static shock.
● Installation or maintenance should be operated by the professional personnel.
● For protection against electric shock, while being assembled or disassembled, make sureconnectors isolated from the power supply.
● Don’t connected or disconnected under load.
● During the assembly process, keep the connector away from any corrosive materials.
