Products Description


Conductor Marking Light for HV-Line Inductive AC Power Night Time Marking Low Intensity Red Obstruction Light on Power Line

Conductor Marking Lights Night time warning lights shall be fitted to phase conductors in flight path of low flying aircrafts. These should be operated by induced currents from the phase conductor and conform to (ICAO) international civil aviation organization and (FAA) Federal aviation authority requirements for light output and visibility. The lights should have an average life of 25,000 hours and should conform to the corona and radio interference requirements of other line hardware.






Item Name
Light for HV-Line
Model
CK-11
Voltage Lines
1V to 500kV
HV Current
30-300A
Operating Line Frequency
50Hz/60Hz
Light intensity
10cd/32.5cd
Life span
＞100,000 hours
Emitting color
RED
Power Consumption
5W
Overall size
350x281x190mm
Ingress protection
IP65
Operating temperature
-40℃～55℃
Net weight
4.1KG
Wind load
80m/sec.
