УГЛЕРОДНЫЙ ЧПУ принтер гравер стекло кожа ручка ювелирные изделия цилиндрический 3d портативный мини-цвет волоконный лазерный гравировальный станок металл 20

Laser type

closed fiber laser

Laser power

20w, 30w, 50w (optional)

Laser wavelength

1064±3

Beam quality

<1.6

Laser jump Q frequency

20kHz-80kHz

Working format

optional (110*110, 150*150, 300*300) mm

Marking depth

≤1

Machine power

≥800w

Minimum line width

0.01mm

Minimum character

0.15mm

Repeatability

±0.0001mm

Scanning speed

8000mm/s

Output power

10%-100% adjustable

Service life

100,000 hours

Compatible system

Windows

Data input

USB

File format

AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, etc.

Input voltage

AC220+10%50HZ/AC110+10%60Hz 10A

Cooling method

air cooling

Dimensions

800*700*1400mm

Bare metal weight

79.5KG

1. The fiber laser marking machine adopts fiber laser, and its service life is up to 100,000 hours. The beam quality is high, and it is the output of the fundamental mode (TEM00). The focused spot diameter is less than 20um. The divergence angle is 1/4 of that of a semiconductor pump laser. The single line is finer, especially suitable for fine and precise marking.
2. Small size, low power consumption; built-in air-cooled cooling mode, abandoning the bulky water-cooled unit, smaller footprint,easier installation, and truly energy-saving and portable.
3. The electro-optical conversion efficiency is high, easy to use, no optical adjustment or maintenance, compact structure, high system integration and few failures.
4. No maintenance required, long service life, suitable for work in harsh environments.
5. The processing speed is 2-3 times that of the traditional marking machine. The optical scanning galvanometer has high laser repetition frequency and high speed without distortion.
6. The fiber lasers are equipped with optical isolators to effectively shield the reflected light. It can be operated on
high-reflection materials such as gold, silver, copper, aluminum and silicon. It does not need to deviate from the center of the field lens and greatly widens it. Application area. And for different metals, it can be applied to a certain color by adjusting the frequency and energy.
7. Marking software is powerful, compatible with software files such as Coreldraw, AutoCAD; support PLT, PCX, DXF, BMP, etc., can directly use SHX, TTF font; support automatic encoding, print serial number, batch number, date, barcode, QR code, automatic jump number, etc., USB interface output control.
