HD 3G SDI выход NDI 10X 20X 30X зум PTZ камера для прямой трансляции видео

Описание и отзывы

Трекер стоимости

Характеристики



Model		H1-P3M	H1-PAM
Image Sensor	Sensor	1/2.8” SONY CMOS
	Effective Pixel	2.1 Megapixel
	White Balance	Auto/Manual
	Backlight Compensation	Support
Lens	Focal Length	f=3.3-10mm	f=4.7-47mm
	Focus	Auto Focusing
	Iris	F1.7-F3.0	F1.6-F2.5
	Zoom	3x Optical	10x Optical
	HOV	84°	62°
Video Output Interface		USB 2.0 Type B
Power Supply		Single USB2.0 Cable Power supply or DC 12V Charger optional
Video Output Format		YUY2/MJPEG/H264: 1920*1080P, 1280*720P, 800*600P, 640*480P, 640*360P
Communication Protocol		VISCA, PELCO-D, UVC
Min. Focus distance		Support minimum distance 12cm	N/A
Baud Rate		2400bps/4800bps/9600bps/38400bps
Preset Position		64
OSD Menu		Support
Image Flip		Support Image Flip/Mirror
Pan Movement Speed		330° , 1-24°/s
Tilt Movement Speed		-30°~ +30°, 1-24°/s
Remote Controller		IR Wireless Remote Controller P/T/Z
Work Temperature		0-50℃
Work Humidity		0-95%RH
Dimension		Camera: 180mm*112mm*129mm
		Packing: 302mm*218mm*120mm
Weight		520g	550g

Q1: Which kind of software does your camera compatible with?

A:Our cameras are compatible with WebEx, Skype for business ,Zoom.us,  Join.me, Vidyo, Lync,Gotomeeting,Blue Jeans, Cisco,

Vsee, and  Awaya platform.



Q2:What are the pixels of this product? Can shoot a full flat conference room?

A:The pixels of this product is 2.10 million. and it can shoot a full meeting room if camera put in the end/front of the conference

room!



Q3:What kind of cameras should I use?

A: It depends on your meeting room spaces, we provide entry-level cameras for huddle rooms,and we also provide 3x, 10x, 20x

and 30x PTZ cameras for larger meeting rooms. Q4:Is it easy to operation? A:One step to Plug-in, Driver free, Plug&Play



Q5: What's your MOQ of video conferencing camera?

A: We accept small quantity orders to support your business growing up step by step,and we ensure the 100% quality of each

camera.



Q6: Is your video conferencing camera quality certified?

A: Yes. Oneking has more than 16 years OEM/ODM experience and we can provide the professional certificates for our video

conferencing camera, such as UL, FCC, CE, WEEE, PSE, ROHS, CSA,etc.



Q7 :What is your payment term?

A: We accept Paypal, WU, T/T, FFT, L/C at Sight and Alibaba Trade Assurance.



Q8:What is your warranty period?

A: The warranty period is 24 months.and we provide 36 months for exclusive distributors.



Q9:Can I put my own logo on products?

A:Yes,We Provide OEM/ODM service, We accept customer’s design, logo,lable,package .etc



Q10: How about your delivery time?

A: We have Samples in stock for fast shipping, For bulk order, Pls negotiate with our sales.



Q11:Do you test all your video conferencing camera before delivery?

A: Yes, We have a complete quality assurance control system to ensure full-quality products before delivery.



Q12: Can the camera be mounted upside down on the ceiling?

A: This PTZ conference camera is designed for an upright, vertical orientation and installation on a flat, level surface or tripod and

cannot be installed in an inverted position.
