High Quality Machinery 260t Crawler Crane QUY260 with Best

Цена:17 597 346,00 ₽*

Количество:

Hydraulic Mobile Crawler Crane 260Ton with Factory Price QUY260

1: self-assembly system
2: controllable free slewing
3: free-fall function
4: ergonomic design
5: high efficiency

Item		Value	Remarks
Max. lifting capacity × Radiust × m		260×5
Deadweight with basic boomt		210
Main boom lengthm		20~83
Length of main boom with light boom headm		86~95
Fixed jib lengthm		12~30
Max. lifting capacity of fixed jibt		34
Offset angle of fixed jib°		10,30
Max. length of main boom with fixed jib m		77+30
Luffing jib lengthm		21~60
Max. lifting capacity of luffing jibt		73.5
Main boom angle under luffing jib working condition°		65,75,85
Max. length of main boom with luffing jib m		62+60
Max. speed of single rope on drum	Main winchm/min	110	The 6th rope layer
	Auxiliary winchm/min	110	The 6th rope layer
	ing winchm/min	29X2	The 6th rope layer
	Luffing winchm/min	46	(Optional) The 6th rope layer
Gradeability%		30
Ground pressureMPa		0.115
Overall dimensions (L×W×H)m		10.2×7.6×3.3	Without mast and boom frame
Engine	Rated power/ rotational speed kW/rpm	256/2100
	Max. output torque/ rotational speedNm/rpm	1750/1200
	Emission standard	TIER 3
Crawler gauge ×ground contact length ×track shoe widthmm		6400×8000×1200
