Product Description

Polyester Geogrid For Road Construction\t

Geogrid is woven by polyester yarn as per desired mesh sizes coating water soluble or oil soluble PVC and strength from 15 kN/m to 1200 kN/m(Biaxial type),35-30KN/m to 1000-50KN/M(Uniaxial type)

high intension and tenacity,oclusive force with soil

gravel, erosion resistant, water drainage, light weight.

Reinforce soft soil roadbed, rib side slope of embankment, enhance isolation, inhibit ground deformatio prevent crack by reflection, increase strength of roadbed.

Polyester Biaxial Geogrid Specification
Performance /Specification			PET 20-20	PET 30-30	PET 40-40	PET 50-50	PET 80-80	PET 100-100	PET 120-120
Elongation (%)			3%
Tensile Strength	warp	20	30	40	50	80	100	120
(KN/m)	waft	20	30	40	50	80	100	120
Mes size(mm)			12.7X12.7, 25.4X25.4, 40X40
Roll Width(m)			1-6
Roll Length(m)			50-200

Polyester Uniaxial Geogrid Specification
Performance /Specification			PET 40-25	PET 50-35	PET 60-30	PET 80-30	PET100-30	PET 120-30
Tensile Strength	warp	25	50	30	30	30	30
(KN/m)	waft	40	35	60	80	100	120
Performance /Specification			PET 150-30	PET 180-30	PET 200-30	PET 300-30	PET 400-30	PET 500-30
Elongation (%)			3%
Tensile Strength	warp	30	30	30	30	30	30
(KN/m)	waft	150	180	200	300	400	500
Mes size(mm)			12.7X12.7, 25.4X25.4, 40X40
Roll Width(m)			1-6
Roll Length(m)			50-200

Product Application

roadbed reinforce of road and railway,

crack prevent, increase roadbed strength

reinforcement and stabilization of riverside, embankment and side slope

dyke reinforcement on soft ground for stress evenness, sedimentation adjustment

reinforcement of the surface of road and bridge,increase of stablity and loading capacity of fundus
