Ковшовый лифт для зерна порошковый материал
- Категория: Material Handling Equipment Parts >>>
- Поставщик: Qingdao,Jiaodong,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.85 $* | 0.98 $* |
| Aug-18-2025 | 0.73 $* | 0.77 $* |
| Jul-18-2025 | 0.5 $* | 0.54 $* |
| Jun-18-2025 | 0.38 $* | 0.49 $* |
| May-18-2025 | 0.69 $* | 0.45 $* |
| Apr-18-2025 | 0.2 $* | 0.35 $* |
| Mar-18-2025 | 0.40 $* | 0.68 $* |
| Feb-18-2025 | 0.51 $* | 0.50 $* |
| Jan-18-2025 | 0.33 $* | 0.92 $* |
Характеристики
Performance description
Product features:
Product features:
1. Gravity unloading, low linear speed
2. No backflow of materials, no crushing
3. Automatic belt tensioning function
4. Good sealing and no noise during operation
5. Convenient disassembly and assembly of the lower seat of the machine, safe and reliable
Cause analysis of bucket elevator blockage:
1. Operation error: blockage caused by feeding before starting. It is necessary to remove blocked materials. When starting the hoist equipment, it shall be carried out in strict accordance with the operating procedures. After the empty machine is started and tested to be normal, it can be fed for use.
2. The material is too large: there may be large pieces of material entering the base, resulting in blockage. It is necessary to shut down the machine to remove large pieces of material and blocked materials;
3. Excessive feeding amount: the feeding amount of the hoist is too large, exceeding the rated lifting and conveying capacity, resulting in blockage. After removing the blocked material, adjust the feed control panel or control the feed flow by other methods.
4. tensioning device: the belt tension is not enough, resulting in slippage causing blockage. After removing the blockage material, adjust the tensioning device and tighten the belt.
1. Operation error: blockage caused by feeding before starting. It is necessary to remove blocked materials. When starting the hoist equipment, it shall be carried out in strict accordance with the operating procedures. After the empty machine is started and tested to be normal, it can be fed for use.
2. The material is too large: there may be large pieces of material entering the base, resulting in blockage. It is necessary to shut down the machine to remove large pieces of material and blocked materials;
3. Excessive feeding amount: the feeding amount of the hoist is too large, exceeding the rated lifting and conveying capacity, resulting in blockage. After removing the blocked material, adjust the feed control panel or control the feed flow by other methods.
4. tensioning device: the belt tension is not enough, resulting in slippage causing blockage. After removing the blockage material, adjust the tensioning device and tighten the belt.
Handling method of bucket elevator blockage:
1. If the hoist hopper is blocked, stop the machine immediately (stop feeding);
2. Take out the insert plate at the lower part of the elevator base and use tools to remove blocked materials;
3. For safety reasons, it is strictly prohibited to reach into the hoist base directly to pick up blocked materials.
1. If the hoist hopper is blocked, stop the machine immediately (stop feeding);
2. Take out the insert plate at the lower part of the elevator base and use tools to remove blocked materials;
3. For safety reasons, it is strictly prohibited to reach into the hoist base directly to pick up blocked materials.
