Super quiet cold weather ultratemp oversized jacuzzi 30m3 to 100m3 indoor or outdoor pool heat
- Категория: Water Heaters >>>
- Поставщик: Power,World,Machinery,Equipment,Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 812.88 $* | 853.85 $* |
| Aug-15-2025 | 805.91 $* | 845.99 $* |
| Jul-15-2025 | 675.47 $* | 709.86 $* |
| Jun-15-2025 | 791.77 $* | 831.85 $* |
| May-15-2025 | 689.41 $* | 723.11 $* |
| Apr-15-2025 | 777.75 $* | 816.92 $* |
| Mar-15-2025 | 771.83 $* | 810.56 $* |
| Feb-15-2025 | 764.45 $* | 802.85 $* |
| Jan-15-2025 | 757.65 $* | 795.96 $* |
Характеристики
Products Description
Model | PW010-KZXYC-B | PW015-KZXYC-B | PW020-KZXYC-B | PW030-KZXYC-B | PW040-KZXYC-B | PW050-KZXYC-B | ||||||
Advised pool volume (m3) | 15~30 | 20~40 | 25~50 | 30~60 | 40~75 | 55~100 | ||||||
Operating air temperature (℃) | -7 ~43 | |||||||||||
Performance Condition: Air 27°C, Water 26°C, Humidity 80% | ||||||||||||
Heating capacity (kW) | 7.50~1.92 | 9.50~2.10 | 11.00~2.50 | 14.00~3.15 | 17.00~3.75 | 20.00~4.00 | ||||||
Heating Capacity(Btu) | 25500~6528 | 32300~7140 | 37400~8500 | 47600~10710 | 57800~13090 | 68000~13600 | ||||||
Consumed power (kW) | 1.15~0.13 | 1.46~0.14 | 1.83~0.17 | 2.15~0.21 | 2.62~0.25 | 3.33~0.27 | ||||||
COP | 6.5~14.8 | 6.5~15.0 | 6.0~14.7 | 6.5~15.0 | 6.5~15.0 | 6.0~14.8 | ||||||
COP at 50% capacity | 10.50 | 11.00 | 11.00 | 10.50 | 11.00 | 11.00 | ||||||
Performance Condition: Air 15°C, Water 26°C, Humidity 70% | ||||||||||||
Heating capacity (kW) | 5.80~1.42 | 7.2~1.50 | 8.5~1.65 | 10.7~2.40 | 13.0~2.65 | 15.6~2.85 | ||||||
Heating Capacity(Btu) | 19720~4828 | 24480~5100 | 28900~5610 | 36380~8160 | 44200~9010 | 53040~9690 | ||||||
Consumed power (kW) | 1.15~0.20 | 1.43~0.21 | 1.77~0.23 | 2.12~0.34 | 2.58~0.36 | 3.25~0.40 | ||||||
COP | 5.0~7.1 | 5.0~7.2 | 4.8~7.2 | 5.0~7.1 | 5.0~7.4 | 4.8~7.0 | ||||||
COP at 50% capacity | 6.50 | 6.50 | 6.50 | 6.50 | 6.50 | 6.50 | ||||||
Performance Condition: Air 35℃,Water 28℃, Humidity 80% | ||||||||||||
Cooling capacity (kW) | 4.0 | 5.2 | 6.0 | 7.2 | 8.6 | 10.1 | ||||||
Sound pressure at 1m dB(A) | 38~48 | 38~48 | 40~50 | 42~51 | 43~52 | 43~53 | ||||||
Sound pressure of 50% capacity at 1m dB(A) | 40 | 40 | 41 | 43 | 44 | 44 | ||||||
Sound pressure at 10m dB(A) | 18~25 | 18~25 | 19~26 | 22~27 | 23~30 | 24~31 | ||||||
Heat exchanger | Spiral titanium tube in PVC | |||||||||||
Casing | Metal Casing | |||||||||||
Power supply | 230V/1 Ph/50Hz | |||||||||||
Water Connection (mm) | Φ50 | |||||||||||
Rated input current at air 15℃（A） | 5.1~0.9 | 6.3~0.9 | 7.8~1.0 | 9.3~1.5 | 11.3~1.6 | 14.3~1.8 | ||||||
Advised water flux (m³/h) | 2~4 | 2~4 | 3~5 | 4~6 | 6~9 | 8~10 | ||||||
Water Pressure Drop (max) kPa | 2 | 3 | 4 | 5 | 5 | 6 | ||||||
Net weight/Gross weight（kg) | 62/70 | 62/70 | 64/72 | 77/87 | 81/91 | 81/91 | ||||||
Carton size（mm） | 980*402*636 | 1107*503*760 | ||||||||||
Refrigerant consumption （g） | 350g | 440g | 450g | 550g | 750g | 800g | ||||||
Why Choose Us
Power World New Energy Technology Co.,Ltd.
Power World has a heat pump R&D center with a team of 20 engineersand four professional laboratories. Complying with ISO9001: 2008&ISO14001: 2004,all products get CE, CB (IEC) certificate and ERP Energy Label based on EN14825, EN14511,strictly according to latest EHPA requirement.
