Высококачественный ручной вилочный погрузчик мощность 1 2 тонн 1200 кг автоматический Электрический укладчик с полной мощностью для пешеходов двигатель постоянного тока 600
- Категория: Material Handling Equipment >>>
- Поставщик: Welift,Machinery,(Changhzou),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 2023.98 $* | 2124.66 $* |
| Aug-19-2025 | 2006.49 $* | 2106.36 $* |
| Jul-19-2025 | 1683.62 $* | 1767.28 $* |
| Jun-19-2025 | 1972.81 $* | 2071.88 $* |
| May-19-2025 | 1717.28 $* | 1803.38 $* |
| Apr-19-2025 | 1938.26 $* | 2035.30 $* |
| Mar-19-2025 | 1921.8 $* | 2017.53 $* |
| Feb-19-2025 | 1904.3 $* | 1999.19 $* |
| Jan-19-2025 | 1887.68 $* | 1981.40 $* |
Характеристики
Model | ES-10P/12P/15P | ||||||
Drive Mode | Electric | ||||||
Operator type | Walkie | ||||||
Load capacity | kg | 1000/1200/1500 | |||||
Load center | mm | 500 | |||||
Tyre type | PU/PU | ||||||
Loading wheel | mm | Φ85*70 | |||||
Driving Wheel | mm | Φ210*70 | |||||
Balance Wheel | mm | Φ130*55 | |||||
Wheel Quantity Driving Wheel/Balance Wheel | 2002/1/1 | ||||||
/Bearing Wheel | |||||||
Mast type | 2 mast | ||||||
Standard lift height | mm | 2000/2500/3000/3500 | 4000 | ||||
Mast lowered height | mm | 1580/1830/2080/2330 | 2580 | ||||
Free lift height | mm | Optional | |||||
Max. extend height | mm | 2560/3060/3560/4060 | 4560 | ||||
Fork lowered height | mm | 85 | |||||
Overall length | mm | 1710 | |||||
Wheel base | mm | 1185 | |||||
Overall width | mm | 800 | 800/1200 | ||||
Fork dimensions | mm | 1150/160/60 | |||||
outside width of the forks | mm | 685/560 | |||||
Aisle width for pallets 1000*1200 crossways | mm | 2300 | |||||
Aisle width for pallets 800*1200 lengthways | mm | 2250 | |||||
Turning radius | mm | 1366 | |||||
Travel speed,laden/unladen | km/h | 3.5/4 | |||||
Lifting speed,laden/unladen | mm/s | 80/125 | |||||
Lowering speed,laden/unladen | mm/s | 150/100 | |||||
Max.gradeability,laden/unladen | % | 3月6日 | |||||
Power of driving motor | KW | 0.75 | |||||
Power of lifting motor | KW | 2 | |||||
Brake type | Electromagnetic | ||||||
Battery capacity/voltage | V/Ah | 24/80, 24/100 | |||||
Controller | V/Ah | Curtis | |||||
Weight of battery | kg | 52/70 | |||||
Weight (with battery) | kg | 576/611/646/681 | 716 | ||||
5.5 | Controller | CURTIS | |||||
5.6 | Steering system | Electronic | |||||
Weight | |||||||
6.1 | Battery weight | kg | 160 | ||||
6.2 | Service weight with battery | kg | 720 | ||||
Advantages: | |||||||
Capacity:2000kg,Original Curtis Controller, fork size: 550*1150/680*1200mm, both lifting up and down,driving are electric,high efficient. Lead-acid battery 24V/165Ah,outside automatic charger with strong power. Quality German Bucher pump motor and other quality parts,Multi-function integrated handle. Equipped with double cylinder, and electronic steering system,electromagnetic/regenerative brake system. AC free maintenance motor, without carbon brush. Stepless speed control,easy to operate for driver. Emergency stop/hour meter/battery level indicator. Foldable platform and protection arms make the operation more fast and efficient. | |||||||
FAQ
1.What's the Certificate do you have?
All our products are confirmed with ISO 9001/CE/CIQ Standard
2.Can you customize and design as the clients' requirement?
We have our own R&D and design team to expand the product line
Customized service: ①Customize non-standard models;
②Customize color, logo and manuals;
③ Professional design plan;
3.What's the payment terms do you accept?
Payment method: T/T, LC,...
4.How long is the warranty of your products?
12-months Warranty
5.Delivery time:
Short lead time: about 10-25days
