Palfinger SPS8000 3 2 тонный кран-манипулятор жесткая стрела
- Категория: Truck Cranes >>>
- Поставщик: Sinomada,Heavy,Industry,(Changsha),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 10710.83 $* | 11246.92 $* |
| Aug-20-2025 | 10620.40 $* | 11151.80 $* |
| Jul-20-2025 | 8910.65 $* | 9356.30 $* |
| Jun-20-2025 | 10440.63 $* | 10962.0 $* |
| May-20-2025 | 9090.39 $* | 9545.37 $* |
| Apr-20-2025 | 10260.46 $* | 10773.16 $* |
| Mar-20-2025 | 10170.9 $* | 10679.20 $* |
| Feb-20-2025 | 10080.58 $* | 10584.81 $* |
| Jan-20-2025 | 9990.86 $* | 10490.63 $* |
Характеристики
Palfinger SPS8000 3.2 Ton Truck-mounted Stiff Boom Crane
Robust, reliable, and service friendly design
Network of modular components connected through standardized interfaces
All the series are equipped with high-pressure filter as standard configuration, it protects the hydraulic components of the crane and prolongs the service life of the hydraulic system
| project | unit | SPS8000A | SPS8000B | |
| Rated contained mass hanging | Rated lifting weight | Kg | 3200 | 3200 |
| Rated lifting torque | Rated lifting moment | Tm | 8 | 8 |
| Maximum working range | Max outreach | m | 7.8 | 10.2 |
| Maximum lifting height | Max lifting height | m | 9.8 | 12.5 |
| Basic boom arm length | Length of the basic boom | m | 3.4 | 3.5 |
| Long boom with outriggers | Length of the fully extended boom | m | 8.0 | 10.4 |
| Number of boom sections | Numbers of the boom | / | 3 | 4 |
| The basic cross-sectional form of arm | Profile method of the basic boom | / | hexagon | hexagon |
| Luffing angle range | Range of the boom lifting angle | . | 0-75 | 0-75 |
| Rotation angle | Slewing angle | . | Full swing | Full swing |
| Leg span (fully extended) | Outrigger span | mm | 4400 | 4400 |
| Recommended system flow | Recommended volume for the system | L / min | 35 | 35 |
| Recommended Fuel tank capacity | Recommended oil tank volume | L | 100 | 100 |
| Crane weight | Weight of the crane | Kg | 1200 | 1300 |
| System rated pressure | Operating pressure | Mpa | 23/25 | 23/25 |
