Вакуумная сушильная машина для фруктов 200 кг 20 м2 промышленного использования чипсы PLC + сенсорный экран 500 нагрев масла ISO CE TUV амбиционные 65
- Категория: Freeze Drying Equipment >>>
- Поставщик: Zhucheng,Tianshun,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.93 $* | 0.83 $* |
| Aug-15-2025 | 0.65 $* | 0.8 $* |
| Jul-15-2025 | 0.14 $* | 0.53 $* |
| Jun-15-2025 | 0.56 $* | 0.70 $* |
| May-15-2025 | 0.34 $* | 0.17 $* |
| Apr-15-2025 | 0.26 $* | 0.44 $* |
| Mar-15-2025 | 0.27 $* | 0.84 $* |
| Feb-15-2025 | 0.43 $* | 0.79 $* |
| Jan-15-2025 | 0.76 $* | 0.25 $* |
Характеристики
Industrial Fruit Vacuum Freeze Drying Machine
1. Industrial Fruit Vacuum Freeze Drying Machine Introduction
The Fruit Freeze Drying Machine is mainly composed of freezing chamber, refrigeration system, vacuum system, heating system and control system.
The Vacuum Freeze Drying Machine is to freeze the water in the materials into a solid condition by freezing, and then sublimate the solid water ice into water vapor by the vacuum and heating, so as to achieve the purpose of dehydration.
The Vacuum Freeze Drying Machine is to freeze the water in the materials into a solid condition by freezing, and then sublimate the solid water ice into water vapor by the vacuum and heating, so as to achieve the purpose of dehydration.
2. Industrial Vacuum Fruit Freeze Dryer Machine Specifications
1).The freeze-dried box and shelf are made in strict accordance with GMP standard. The cylinder is made of 304 stainless steel,and the interior is mirror polished.
2).Integrated design of box body and cold trap, and there is an observation window for easy observation of the situation in the box.
3).Drying rate more than 99%.
4).Refrigeration components are configured by high-standard imported brands, with strong cooling capacity, fast cooling speed,stable and reliable performance.
5).PLC control system, convenient to store data and easier to master, with auto/manual control modes.
6).Water circulation heating to defrost, quickly defrost and clean.
2).Integrated design of box body and cold trap, and there is an observation window for easy observation of the situation in the box.
3).Drying rate more than 99%.
4).Refrigeration components are configured by high-standard imported brands, with strong cooling capacity, fast cooling speed,stable and reliable performance.
5).PLC control system, convenient to store data and easier to master, with auto/manual control modes.
6).Water circulation heating to defrost, quickly defrost and clean.
Model | TSFD-20 | TSFD-30 |
Power | 65kw | 79kw |
Drying area | 20m2 | 30m2 |
Batch capacity | 200kg | 300kg |
No's of trays | 22 | 26 |
Nos' of shelf | (11+1)*2 | (13+1)*2 |
Overall size | 1950*1460*1660mm | 7050*2550*3500mm |
3. -Industrial Freeze Dried Fruit Machine Detailed Parts
4.-Freeze Dried Fruit Making Machine Applications
The Vacuum Freeze Drying Machine apply to process wide range of products below:
1)Freeze Dried Vegetables: edible mushroom, sliced garlic, chives, onion, green beans, peas, cucumber, sweet corn, diced carrot,
spinach, asparagus, edible wild herbs, etc.
2)Freeze Dried Seafood: Conpoy, shrimp meat, fish fillets, sea cucumber,etc.
3)Freeze Dried Meat: Beef, pork, chicken, mutton, duck, etc.
4)Freeze Dried Flavored Products: garlic powder, ginger powder, onion powder, tomato, pepper powder;
5)Instant Soluble beverage: Coffee, tea, soup, soymilk, milk, etc.
6)Freeze Dried Fresh Medicines: ginseng, pilose antler, chines wolfberry, etc.
7)Freeze Dried Pet food: Quail, egg yolk, salmon, dried fish, etc.
1)Freeze Dried Vegetables: edible mushroom, sliced garlic, chives, onion, green beans, peas, cucumber, sweet corn, diced carrot,
spinach, asparagus, edible wild herbs, etc.
2)Freeze Dried Seafood: Conpoy, shrimp meat, fish fillets, sea cucumber,etc.
3)Freeze Dried Meat: Beef, pork, chicken, mutton, duck, etc.
4)Freeze Dried Flavored Products: garlic powder, ginger powder, onion powder, tomato, pepper powder;
5)Instant Soluble beverage: Coffee, tea, soup, soymilk, milk, etc.
6)Freeze Dried Fresh Medicines: ginseng, pilose antler, chines wolfberry, etc.
7)Freeze Dried Pet food: Quail, egg yolk, salmon, dried fish, etc.
5.-Projects
6.-Packing & Delivery
7.-Company Profile
Zhucheng Tianshun Machinery Co., Ltd. is a modern food machinery manufacturer integrating
R&D, manufacturing, marketing and after-sales.
It mainly produces complete sets of equipment such as food frying equipment, cleaning equipment, blanching and cooking equipment,low-temperature sterilization machines, quick-freezing equipment, vacuum freeze-drying, drying equipment, packaging equipment,fruit and vegetable cutting equipment, and food processing production lines. The equipment is mainly for fruit and vegetable,aquatic products, meat, pasta, central kitchen, medicinal materials, pet food and other processing enterprises.
R&D, manufacturing, marketing and after-sales.
It mainly produces complete sets of equipment such as food frying equipment, cleaning equipment, blanching and cooking equipment,low-temperature sterilization machines, quick-freezing equipment, vacuum freeze-drying, drying equipment, packaging equipment,fruit and vegetable cutting equipment, and food processing production lines. The equipment is mainly for fruit and vegetable,aquatic products, meat, pasta, central kitchen, medicinal materials, pet food and other processing enterprises.
