Абсолютно Новый hrc-3 penetratore для твердомер машина испытания по шкале Роквелла инструменты отличной


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 0.54 $* 0.30 $*
Aug-18-2025 0.93 $* 0.64 $*
Jul-18-2025 0.89 $* 0.30 $*
Jun-18-2025 0.78 $* 0.87 $*
May-18-2025 0.76 $* 0.32 $*
Apr-18-2025 0.22 $* 0.0 $*
Mar-18-2025 0.53 $* 0.31 $*
Feb-18-2025 0.93 $* 0.45 $*
Jan-18-2025 0.1 $* 0.65 $*

Характеристики




Application:



  1. Automatic testing process, put the sample, press the "Start" button to obtain the hardness value of each sample
  2. Samples automatically rise (no height restrictions)
  3. Automatic initial test force is applied, the main test force is automatically applied
  4. Automatic measurement of hardness, hardness values of automatic digital display
  5. Touch screen interface, easy operation, multi-language versions
  6. Available for using after staring up, unnecessary for installing weights and Debugging
  7. Electric loading, closed-loop control
  8. Automatically apply the initial load and main load
  9. Automatic correction of high, medium and low hardness numbers
  10. Automatic correction of load, with the force accuracy increased by a numerical level



Specifications:



Model

HRS-150TDX-Z

HRS-45TDX-Z

HRS-150/45TDX-Z

Exchanging scales

Rockwell, Brinell, Vicker

Configuration

Z axis rising

Samples rise

Automatic

Automatic sample rate rise

3mm/s

Hardness testing range

HRA: 20-96 HRB: 20-100 HRC: 20-70 HRD: 40-77 HRE: 70-100 HRF: 60-100 HRG: 30-94HRH: 80-100 HRK: 40-100 HRL: 50-115 HRM: 50-115 HRR: 50-115

Testing rage of Superficial Rockwell

HR15N: 70-94; HR30N: 42-86; HR45N: 20-77;HR15T: 67-93; HR30T: 29-82; HR45T: 10-72

Rockwell initial test force

10kgf(98.07N)

3.0kgf(29.4N)

10kgf(98.07N),3.0kgf(29.4N)

Rockwell total test force

60kgf(588N)   100kgf(980N)   150kgf(1471N)

15kgf(147.1N)   30kgf(249.2N)   45kgf(441.3N)

60kgf(588N),100kgf(980N)   150kgf(1471N),15kgf(147.1N),30kgf(249.2N),45kgf(441.3N)

Dwell time

0-60s

Hardness resolution

0.1HR

Test force error

<1.0%

Carried standard

GB/T230.1 GB/T230.2 national standard JJG112 verification regulation

Max. Height of sample

220mm

The distance of indenter to the wall

200mm
