Plastic Bag Recycling Pelletizer Pp Granules Making Machine
- Категория: >>>
- Поставщик: Shenyang,Beiteng,Chemical,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 8658.59 $* | 9091.43 $* |
| Aug-16-2025 | 8586.52 $* | 9015.46 $* |
| Jul-16-2025 | 7203.19 $* | 7563.39 $* |
| Jun-16-2025 | 8440.18 $* | 8862.76 $* |
| May-16-2025 | 7349.44 $* | 7716.12 $* |
| Apr-16-2025 | 8295.98 $* | 8710.28 $* |
| Mar-16-2025 | 8222.2 $* | 8633.25 $* |
| Feb-16-2025 | 8149.84 $* | 8556.98 $* |
| Jan-16-2025 | 8076.39 $* | 8480.99 $* |
Характеристики
Product Description
The main machine of the plastic granulator is an extruder, which is composed of extrusion system, transmission system and heating and cooling system.
Product introduction:
Plastic granulator is mainly used for processing of waste plastic film (industrial packaging film, agricultural film, greenhouse film, beer package, bag, etc.), woven bags, agricultural convenience bag, basin, barrels and bottles, furniture, supplies, etc., suitable for most common waste plastic, waste plastic recycling industry is used most widely, the most widely used, the most popular plastic processing machinery.
Note: Before you make an inquiry, we need to know the finished products you want to produce and the production capacity！
Model | Power kW | Spindle length mm | Output kg/h | Speed r/mi |
ZLJ-110 | 22 | 2000 | 100-130 | 60-70 |
ZLJ-125 | 30 | 2200 | 120-150 | 60-70 |
ZLJ-135 | 30-37 | 2400 | 130-180 | 60-70 |
ZLJ-145 | 37-45 | 2400 | 200-250 | 60-70 |
ZLJ-155 | 37-45 | 2500 | 250 | 60-70 |
ZLJ-165 | 45-55 | 2700 | 250-300 | 60-70 |
ZLJ-175 | 45-55 | 2800 | 250-300 | 60-70 |
ZLJ-185 | 55-75 | 3000 | 300-350 | 60-70 |
ZLJ-200 | 75 | 3200 | 400-450 | 60-70 |
ZLJ-220 | 75-90 | 3200 | 450-500 | 60-70 |
ZLJ-230 | 90-110 | 3500 | 500 | 60-70 |
ZLJ-260 | 110-132 | 4000 | 500-600 | 60-70 |
ZLJ-280 | 132 | 4500 | 600-650 | 60-70 |
ZLJ-300 | 132-160 | 5000 | 650-750 | 60-70 |
Plastic granulator details advantages
1.The extrusion system includes hopper and head. The plastic is plasticized into uniform melt through the extrusion system, and the extrusion head is continuously extruded by the screw under the pressure established in this process.
2. The function of the transmission system is to drive the screw and supply the torque and speed required by the screw in the extrusion process. It is usually composed of motors, reducers and bearings.
3. Heating and cooling equipment Heating and cooling are necessary conditions for the plastic extrusion process to be carried out.
2. The function of the transmission system is to drive the screw and supply the torque and speed required by the screw in the extrusion process. It is usually composed of motors, reducers and bearings.
3. Heating and cooling equipment Heating and cooling are necessary conditions for the plastic extrusion process to be carried out.
Working principle:
Extruding machine in accordance with the head flow direction and the screw center line angle, the head is divided into oblique head (included angle 120) and right angle head. The shell of the machine head is fixed on the fuselage with bolts, the mold in the machine head is seated, and the screw nut is fixed on the machine head into the line port, the front of the mold core seat is equipped with the mold core, the center of the mold core and the mold core seat has a hole, for through the core wire; A pressure equalizing ring is arranged in the front of the nose for equalizing the pressure; The extrusion forming part is composed of a die sleeve seat and a die sleeve. The position of the die sleeve can be adjusted by bolts through support to adjust the relative position of the die sleeve to the die core, which is easy to adjust the uniformity of the thickness of the extrusion layer. The head is equipped with a heating device and a temperature measuring device.
Extruding machine in accordance with the head flow direction and the screw center line angle, the head is divided into oblique head (included angle 120) and right angle head. The shell of the machine head is fixed on the fuselage with bolts, the mold in the machine head is seated, and the screw nut is fixed on the machine head into the line port, the front of the mold core seat is equipped with the mold core, the center of the mold core and the mold core seat has a hole, for through the core wire; A pressure equalizing ring is arranged in the front of the nose for equalizing the pressure; The extrusion forming part is composed of a die sleeve seat and a die sleeve. The position of the die sleeve can be adjusted by bolts through support to adjust the relative position of the die sleeve to the die core, which is easy to adjust the uniformity of the thickness of the extrusion layer. The head is equipped with a heating device and a temperature measuring device.
Company Profile
Shenyang Beiteng Chemical Machinery Co., Ltd. is an enterprise integrating scientific research, development, production and sales, and a technology backbone enterprise in the domestic machinery and equipment industry.
Location and technology development：
The company is located in China's heavy industrial base-Aiguo Village, Daxing Street, Yuhong District, Shenyang, and the production base is located in Shaling Industrial Park, Yuhong District, Shenyang enjoying superior geographical position and convenient traffic. Beiteng is mainly engaged in the R&D, production and sales of chemical machinery, plastic machinery, reaction kneading industry and thermal insulation dry powder mortar production line. We have strong technical force, the advanced level of technology and rational process. Also we are equipped with a complete product production and quality assurance system and perfect after-sales service. Our products are under the guidance of professional engineers, we strictly control the process and production steps to ensure the quality of the products. Our company passed the IS09001 international quality system certification in 2004. We have persisted in developing with high quality for many years, and regard the quality control of the production management process as important as the advanced design. In the meanwhile, we strictly implement all the steps in accordance with the technical requirements of national standards and trade standards. All along, our products are aimed to achieve best interest for users with our excellent quality and perfect after-sales service system.
Why Choose Us
Our company provides technical raw materials and product formulations.In the new situation of economic globalization and world integration, our price has enough advantages, and our after-sales service is very perfect.
Certifications
After sales
Perfect service system Beiteng Machinery 13940259778 15802483669
Five quality services before sale /in sale /continuous service after sale
1.Freely design suitable equipment collocation scheme.
2.Freely high-quality modeling scheme design,recommend equipment and design CAD drawings according to user needs.
3.Provide material processing experiments and formulations.
4.Free technical guidance, inform users of product operation and maintenance , and fully cooperate with users to complete the installation of the equipment until normal operation.
5.Free technical personnel troubleshooting, if the user due to equipment damage,only need to pay the cost of accessories.
Packing And Shipping
FAQ
Q: Are you a machinery factory or a trading company?
A: We are a machinery factory with 13 years of experience in Shenyang. Annual export sales account for 30% of the total sales.
Q: What kind of machine do you make?
A: We mainly produce plastic machinery and chemical machinery.
Q: How to ensure the quality?
A: We are specialized in the design, sales, installation and maintenance of mechanical equipment for 13 years, with a strong technical team to escort you.
Q: How about the delivery time?
A:We have it in stock, but it takes about 3-7 working days for a new ordinary machine to be produced, and the goods are usually shipped within 15 working days.
Q: How long is the warranty?
A: Within one year from the customer's confirmation of receipt, if there is any non-human failure or damage (except for vulnerable parts), we will provide new parts free of charge.
Q: What are your payment terms?
A: 100% telegraphic transfer before shipment. L / C Western Union remittance or trade guarantee order is recommended before shipment.
