Professional PCB cutting machine supplier Automatic online PCB cutter with high precision
Working process of orbital online PCB cutting machine :
The PCBA board carrier to be divided flows into the conveying track of the equipment, the inductor senses and blocks the cylinder from extending, the fixture is in place and the jack cylinder extends. After the carrier is positioned, the equipment starts to split the board and blocks the cylinder from retracting. After the split is completed, the jack cylinder retracts and the fixture flows to the next station; Repeat the cycle. Adapt to heavy industry of circuit board such as automobile electronic power server
Features of orbital online PCB cutting machine :
1. High-precision:
CCD automatic recognition mark point positioning and compensation, ensure the high precision of cutting. Exquisite visual system, improve the efficiency of programming, convenience and stability
2. Easy to operate:
Using Windows 7 Chinese and English operation interface, programming is simple, easy to learn and use
3. superior quality:
Anti static brush type dust collection device, dust collection rate increased by 90%, high cleanliness
PCBA cutting stress < 200 με The cutting surface is flat and smooth
4. High reliability cutting:
The rotating part is driven by servo, and the cutting is divided by the imported high-speed spindle; It is suitable for all kinds of circuit boards, such as linear, L-shaped, U-shaped, circular, arc, special-shaped, etc
5. Vehicle positioning: PCBA circuit board to achieve high precision cutting, with anti dummy inspection, line performance is stable and reliable
Parameters of orbital online PCB cutting machine:
Model
OB-C668J
Cutting size
X500*Y300mm (customized)
Fixture size
600*400mm(customized)
Blade break detection
Yes
Transport mode
Fixture flows into the equipment conveyor
Direction
L-R or R-L
Cutting function
straight line, circular and circular interpolation
Repeat precision
±0.01mm
Cutting precision
±0.05mm
Max. moving speed
XY 800mm/s、Z 350mm/s
Max. moving range
X:810 Y:370 Z:90mm
Spindle speed
MAX. 20000-60000rpm
Cutting speed
1~100mm/s (adj)
Operate interface
operation interface windows7
Programing mode
Visual import of color CCD image
Program backup
USB interface
Control method
PC rasem precision intelligent system
XYZ axis drive mode
AC servo motor
Milling cutter size
ψ0.8~3.0mm
Power supply
AC220V 50/60HZ
Dimensions
1250*1250*1550mm
Weight
1000kgs
