Система солнечной энергии трехфазный электронный измеритель Modbus с двунаправленным
- Категория: Energy Meters >>>
- Поставщик: Shanghai,Ivy-Metering,Electronic,Technology,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.36 $* | 0.67 $* |
| Aug-19-2025 | 0.82 $* | 0.30 $* |
| Jul-19-2025 | 0.50 $* | 0.66 $* |
| Jun-19-2025 | 0.61 $* | 0.25 $* |
| May-19-2025 | 0.41 $* | 0.94 $* |
| Apr-19-2025 | 0.52 $* | 0.23 $* |
| Mar-19-2025 | 0.40 $* | 0.51 $* |
| Feb-19-2025 | 0.55 $* | 0.67 $* |
| Jan-19-2025 | 0.35 $* | 0.8 $* |
Характеристики
Features
1. Bi-directional Measurement
2. RS485 Modbus RTU & IR
3. MID Approved
5. 5(80)A, 3*240V/400V
Specification | Type | 3 Phase Bi-directional Energy Meter |
Reference Voltage | 3*230/400V | |
Current | 0.25-5(80)A | |
Accuracy Class | Cl.1 | |
Standard | EN50470-1/3. | |
Frequency | 50Hz | |
Impulse Constant | 1000imp/kWh | |
Display | LCD6+2 (Smog-free) | |
Power Consumption | ≤ 1.5W,<10VA | |
Starting Current | 0.004Ib | |
Temp. Range | -20～+70℃ | |
Certificate | MID | |
Annual Average Humidity | 75% | |
Max Humidity | 90% | |
Communication | IR & RS485 | |
Communication Protocol | EN62056 (IEC1107) & Modbus RTU |
Product Description
EM519033-04 is a Three Phase Energy Meter With RS45 Modbus. Its voltage is 3*230V/400V and it can maintain class 1.0 accuracy when 5 to 80A. It is a Bi-directional Meter that has forward and reverse measurement. The three phase electric meter can also measure active energy, voltage, current in each phase.
The electric meter supports Infrared and RS485 Modbus RTU Communication. Therefore, remote control and data monitoring via PC is available. RS485 modbus meter is also a much cheaper and cconomical choice for realizing automatic meter reading.
RS485 Communnication supported maximum 100 Kbps data transmission speed and up to 1200 meters communication range. It supports single master and multiple sub meters due to balanced transmission line. Response time between reader and software is short when less than 32 controllers (or readers) are communicating on same data line
This bi-directional energy meter has programmable multi-tariff and complies with EN50470-1/3 standard. The LCD display is 6+2 and it also has two display modes: auto scrolling and button pressing. In addition, the digital display meter has strong moisture resistance and no condensation.
Our product has quality assurance and the electrical meter has passed and gained MID certicate. As a three phase electricity meter, it is widely applied to industrial area, such as productioh lines, testing area and R&D workshops.
This MID approved meter is suitable and can be widely used for solar energy system and EV charging station. IVY has done several cases on integrating our meters into solar and EV billing system. We may provide detailed technical support for you.
The electric meter supports Infrared and RS485 Modbus RTU Communication. Therefore, remote control and data monitoring via PC is available. RS485 modbus meter is also a much cheaper and cconomical choice for realizing automatic meter reading.
RS485 Communnication supported maximum 100 Kbps data transmission speed and up to 1200 meters communication range. It supports single master and multiple sub meters due to balanced transmission line. Response time between reader and software is short when less than 32 controllers (or readers) are communicating on same data line
This bi-directional energy meter has programmable multi-tariff and complies with EN50470-1/3 standard. The LCD display is 6+2 and it also has two display modes: auto scrolling and button pressing. In addition, the digital display meter has strong moisture resistance and no condensation.
Our product has quality assurance and the electrical meter has passed and gained MID certicate. As a three phase electricity meter, it is widely applied to industrial area, such as productioh lines, testing area and R&D workshops.
This MID approved meter is suitable and can be widely used for solar energy system and EV charging station. IVY has done several cases on integrating our meters into solar and EV billing system. We may provide detailed technical support for you.
Detailed Function
(1) Measurement of forward and reverse energy, total/each phase active energy, total/each phase voltage, total/each phase current, total/each phase active power, power factor and frequency
(2) RS485 Communication Modbus RTU Protocol; IR Communication EN62056（IEC1107) Protocol
(3) Bi-directional Measurement
(4) Certifaicte: MID
(5) Data Monitoring and Energy Quality Analysis by PC
(6) Programmable multi-tariff and friendly hours
(7) High anti-humidity and no condensation
(8) Good reliability, compact size, light weight, easy installation
(2) RS485 Communication Modbus RTU Protocol; IR Communication EN62056（IEC1107) Protocol
(3) Bi-directional Measurement
(4) Certifaicte: MID
(5) Data Monitoring and Energy Quality Analysis by PC
(6) Programmable multi-tariff and friendly hours
(7) High anti-humidity and no condensation
(8) Good reliability, compact size, light weight, easy installation
Cautions:
1.About AC/DC Energy Meter
(1) AC or DC- Generally speaking alternating current or direct current shall be the first factor.
(2) We also have DC meter when you need to measure the Direct Current.
2.About Function
(1) As the content is limited, all functions mentioned above are the main functions
(2) Other functions such as TOU, load control, friendly hours,RTC, plz refer to the technical specification or
(1) AC or DC- Generally speaking alternating current or direct current shall be the first factor.
(2) We also have DC meter when you need to measure the Direct Current.
2.About Function
(1) As the content is limited, all functions mentioned above are the main functions
(2) Other functions such as TOU, load control, friendly hours,RTC, plz refer to the technical specification or
contact with our sales team.
3.About Application
(1) The applications only for examples, for the pratical situation the energy meter can also be used for
3.About Application
(1) The applications only for examples, for the pratical situation the energy meter can also be used for
other applications.
(2) Welcome to inquiry if you are not sure about the functions or application, we have free technical support
(2) Welcome to inquiry if you are not sure about the functions or application, we have free technical support
