Product Description
mobile light boom lifts /articulated folding arm lifting platform
As an expert in the field of aerial work platforms, the 16M articulated aerial work platform adopts a multi-functional design to ensure the safety of operators. It has good maneuverability and can be operated freely even in a small space, and it can easily cross obstacles with the help of a crank arm.
◆ The working range is industry-leading, with a horizontal reach of 8.3 m
◆ It only takes 40 seconds to rise from the ground to the highest point
◆ Full proportional control, multi-action synchronous operation
2. strong and durable
◆ The hood is sturdy and durable, with ergonomic design
◆ Durable structural design
3. Convenient maintenance
◆ Modular design of working platform, equipped with platform control box protection cover
◆ Simple layout of parts and components, convenient for maintenance
◆ Haulotte Activ'Screen (vehicle visualized diagnosis system)
◆ Safe and comfortable operation
Advantages and highlights:
1. Outstanding performance and easy to use
◆ The working range is industry-leading, with a horizontal reach of 8.3 m
◆ It only takes 40 seconds to rise from the ground to the highest point
◆ Full proportional control, multi-action synchronous operation
2. strong and durable
◆ The hood is sturdy and durable, with ergonomic design
◆ Durable structural design
3. Convenient maintenance
◆ Modular design of working platform, equipped with platform control box protection cover
◆ Simple layout of parts and components, convenient for maintenance
◆ Haulotte Activ'Screen (vehicle visualized diagnosis system)
◆ Safe and comfortable operation
Product Paramenters
Item | Parameter | Item | Parameter | ||
Working height | 16m | Swing tail | 10 cm | ||
Platform height | 14m | Wheelbase | 2.1 m | ||
Horizontal reach | 8.3m | Ground clearance | 38 cm | ||
Span height | 7.65m | Tilt angle | 5 ° | ||
Max. Load capacity | 230 kg (2 pers.) | Travel speed | 5.2 km/h | ||
Platform size | 1.83 x 0.80 m | Gradeability | 40% | ||
Collected length | 6.75 m | Min. external turning radius | 4.5 m | ||
Width | 2.3 m | Weight | 6200 kg | ||
Storage height | 2.3 m | Transport length | 5.05 m | ||
Forearm vertical swing | 140° (- 80° / + 60°) | Transport height | 2.4 m | ||
Platform swivel angle | 165° (- 75° / + 90°) | Off-road solid tires | 850 x 340 mm | ||
Slewing angle | 355° discontinuous slewing | Maximum wind speed resistance | 60 km/h | ||
Engine Kubota | 18.5 kW (Stage 5 in EU)-Kubota, 26.5 kW, (Stage 3A in NRC) | ||||
