Строительная машина XGT7020-12 Плоская верхушка башенный кран с конкурентоспособной

Строительная машина XGT7020-12 Плоская верхушка башенный кран с конкурентоспособной

Цена:12 000,00 $*

Количество:

Hot Product Link

Construction machine XGT7020-12 flat top tower crane with competitive price

Product Description

Performance Characteristics:

* The most secure high-end construction lifting machinery benchmark.

* The lifting performance is better than competitors.

* New XGT-AMCS intelligent management system.

* With the speed control function, the position accuracy is up to millimeter; ensure that the hoisting is smooth and accurate.

* Quick disassembly, easy and efficient, the platforms and booms are quick-assembly structures, which save 3.2 hours for installation.

Main Parameter

Type	XGT7020-12
Basic height	60M
Max height	240M
Length	70/65/60/55/50/45/40/35/30
Max load	12t
Tip load	2/2.5/3.1/3.9/4.7/5.6/6.3/7.2/8.5
Section size	2000×2000×3000

Items	Mechanism	Speed(m/min)		Rope capacity	Motor(Kw)
Hoist mechanism	55JLF30A	2 multiplying power	0-90	695M	55
		4 multiplying power	0-45	>695M*
Trolleying mechanism	6JXF5	0-63m/min			5.5
Slewing mechanism	JH12CT6	0-0.66r/min			2×7.5
Travelling	RT	0-25m/min			4×4
Main Supply	380V(±10%)/50Hz*
Gross Power(Excluding climbing and travelling):75.5Kw
