3DSWAY 3D части принтера 1M 6*20 мм керамический картридж электрического нагревательного элемента 12V 24V 50W нагревательная труба для E3D V6 Hotend J-печатающей
- Категория: Printer Supplies >>>
- Поставщик: Shenzhen,Chaihuo,Space,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.19 $* | 0.99 $* |
| Aug-20-2025 | 0.19 $* | 0.50 $* |
| Jul-20-2025 | 0.68 $* | 0.32 $* |
| Jun-20-2025 | 0.30 $* | 0.86 $* |
| May-20-2025 | 0.10 $* | 0.14 $* |
| Apr-20-2025 | 0.60 $* | 0.24 $* |
| Mar-20-2025 | 0.83 $* | 0.75 $* |
| Feb-20-2025 | 0.76 $* | 0.87 $* |
| Jan-20-2025 | 0.85 $* | 0.73 $* |
Характеристики
Products Description
Product name: | Heating tube |
Item Type: | Cartridge Heater |
Voltage: | 12V/24V |
Power: | 50W |
Heating head size: | 6 * 20mm |
Heating head material: | 304 stainless steel |
Application: | 3D printing |
Length: | 1M |
Weight: | 35g |
Single-ended heater instructions
1. The effective heating part of the heater must keep dry.
1. The effective heating part of the heater must keep dry.
2. The electrical connector of the single-ended heater should be placed out of the insulation layer and heating room, and the working voltage shall not exceed its rated value of 10%. The shell should be effectively grounded.
3. Electric components working environment, the temperature should not be greater than 95 degrees, no explosive or corrosive gases.
4. Electric components should be stored in a dry place
Product specifications
Voltage: 12V/24V
Power: 50W
Heating head size: 6 * 20mm
Heating head material: 304 stainless steel
Line length: 1M and 2M for option
Line thick: 0.5 mmsup2; (The cross section of the copper wire inside the heater is 0.5mmsup2;)
Color: as shown in the picture
Heating temperature: up to 350 degrees
Product specifications
Voltage: 12V/24V
Power: 50W
Heating head size: 6 * 20mm
Heating head material: 304 stainless steel
Line length: 1M and 2M for option
Line thick: 0.5 mmsup2; (The cross section of the copper wire inside the heater is 0.5mmsup2;)
Color: as shown in the picture
Heating temperature: up to 350 degrees
The improvement compared to ordinary red heater
1. From the original ordinary 0.3-line high-temperature line to 0.5-line thick white high-temperature line, can bear higher
temperature, and looks more beautiful.
2. From the original 40W power to 50W, therefore, the maximum temperature increases from 300-31℃ to 340-350℃ or so.
3. The new version heater used in all imported skills, the use of 304 stainless steel, with the internal use of 2080 nickel chrome wire to achieve maximum service life.
4. Support the customization of different specifications, length, resistance of the heater.
5. Can be used with the new HT-NTC100K temperature thermistor (Temperature measurement can be up to 350 degrees).
1. From the original ordinary 0.3-line high-temperature line to 0.5-line thick white high-temperature line, can bear higher
temperature, and looks more beautiful.
2. From the original 40W power to 50W, therefore, the maximum temperature increases from 300-31℃ to 340-350℃ or so.
3. The new version heater used in all imported skills, the use of 304 stainless steel, with the internal use of 2080 nickel chrome wire to achieve maximum service life.
4. Support the customization of different specifications, length, resistance of the heater.
5. Can be used with the new HT-NTC100K temperature thermistor (Temperature measurement can be up to 350 degrees).
FAQ
Q1: How to order?
A: First let us know your concrete requirements and address; second we will make performa invoice for your inspection andpayment; then we will delivery the goods asap after your payment.
Q2: What is your terms of payment ?
A: For small amount orders, 100% better paid by PayPal or T/T in advance. For large amount orders like more than 10000USD, 40%T/T in advance , balance fully paid before shipment.
Q3: Do you offer ODM/OEM serive?
A: Yes, but it depends on the qty.
Q4: How long is your delivery time?
A: Normally in 3 working days after payment.
Q5: How do you guarantee my goods right?
A: Order will be arranged exactly as requested, we will check the packing and qty before delivering.
Q6: Do you provide samples ? is it free or extra?
A: As to part of our product, we offer samples with free charge but do not pay the shipping freight.
A: First let us know your concrete requirements and address; second we will make performa invoice for your inspection andpayment; then we will delivery the goods asap after your payment.
Q2: What is your terms of payment ?
A: For small amount orders, 100% better paid by PayPal or T/T in advance. For large amount orders like more than 10000USD, 40%T/T in advance , balance fully paid before shipment.
Q3: Do you offer ODM/OEM serive?
A: Yes, but it depends on the qty.
Q4: How long is your delivery time?
A: Normally in 3 working days after payment.
Q5: How do you guarantee my goods right?
A: Order will be arranged exactly as requested, we will check the packing and qty before delivering.
Q6: Do you provide samples ? is it free or extra?
A: As to part of our product, we offer samples with free charge but do not pay the shipping freight.
