Новый продукт, переносные пилорезы
US $1500-$2000
Сверхмощный Кромкооблицовочный станок/кромкооблицовочная
- Категория: Saw Machines >>>
- Поставщик: Qingdao,Oset,International,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 16422.97 $* | 17243.29 $* |
| Aug-19-2025 | 16284.39 $* | 17098.42 $* |
| Jul-19-2025 | 13662.88 $* | 14345.53 $* |
| Jun-19-2025 | 16008.82 $* | 16808.54 $* |
| May-19-2025 | 13938.74 $* | 14635.75 $* |
| Apr-19-2025 | 15732.40 $* | 16519.43 $* |
| Mar-19-2025 | 15594.93 $* | 16374.62 $* |
| Feb-19-2025 | 15456.46 $* | 16229.28 $* |
| Jan-19-2025 | 15318.57 $* | 16084.78 $* |
Характеристики
Product Description
Specification
Parameters | |||||
Model | SYS-468 | ||||
Panel Thickness | 10-60mm | ||||
Edge Band Thickness | 0.3-3mm | ||||
Panel Width | ≥60mm | ||||
Panel Length | ≥150mm | ||||
Feeding Speed | 15-23m/min | ||||
Working Pressure | 0.6Mpa | ||||
Voltage | 380V/50HZ/3PH | ||||
Gluing Motor | 0.75KW 50HZ 1400RPM | ||||
End Cutting Motor | 0.37KW * 2 200HZ 12000RPM | ||||
Trimming Motor | 0.75KW * 4 200HZ 12000RPM | ||||
Corner Trimming Motor | 0.37KW * 2 200HZ 12000RPM 0.75KW * 2 200HZ 12000RPM | ||||
Buffing Motor | 0.37KW * 2 50HZ 1400RPM | ||||
Conveyor Motor | 2.2KW | ||||
Glue Pot Heating Power | 2.4KW | ||||
Lighting Power | 0.05KW | ||||
Lifting Motor | 0.25KW | ||||
Total Power | 12.4KW | ||||
Dimension | 5670*800*1620mm | ||||
Wooden Crate Package | 5770*900*1720mm | ||||
Dust System Outlet Diameter | 100mm | ||||
Dimension of Wood Packing Carton | 2250*1200*1100mm(Main Crate ) | ||||
3400*450*290mm(Sliding Table) | |||||
Dimension | 3250*3450*900mm | ||||
G. W. | 800KG | ||||
Packing & Loading
Details Images
Company Profile
OSETMAC focuses on woodworking machines for over 8 years. OSETMAC has two wholly-owned manufacturing factories--Qingdao Three One
Three Machinery Company and Qingdao De Tai Wo Machinery Company. Our factories have been well-recognized as a professional
woodworking machine producers. The main products of OSETMAC is sliding table saw, brush sanding machine, edge banding machine,
wood drilling machine and CNC routers. What's more, our products have been sold to more than 30 countries and regions in Middle
East, Southeast Asia, Europe and South America. OSETMAC is able to do our own R&D, deliver production task on time and provide
customer service quickly. The manufacturing factories have already been granted ISO9001, and some of the main products have passed
CE certificate.
Three Machinery Company and Qingdao De Tai Wo Machinery Company. Our factories have been well-recognized as a professional
woodworking machine producers. The main products of OSETMAC is sliding table saw, brush sanding machine, edge banding machine,
wood drilling machine and CNC routers. What's more, our products have been sold to more than 30 countries and regions in Middle
East, Southeast Asia, Europe and South America. OSETMAC is able to do our own R&D, deliver production task on time and provide
customer service quickly. The manufacturing factories have already been granted ISO9001, and some of the main products have passed
CE certificate.
Our Advantages
Features of SYS-468
Features of SYS-468
Description： * 7 Functions: Gluing--End Cutting--Rough Trimming--Fine Trimming--Corner Rounding--Scraping--Buffing * Working
Voltage: 380V/50HZ /3PH * DELTA inverter or MCGS inverter for your choice. * PLC Touch Screen * CC highspeed motor. * The conveyor
speed can be adjusted from 13-25m/min *Honeywell travel switch, contactor, air switch. *Air Tac solenoid valve, air
cylinder,oil-water seperator. * With automatic oil feeder. *14mm high strenth steel sheet for the whole machine. * In the machine
is mounted lights. * Support customization for the machine appearance.
Description： * 7 Functions: Gluing--End Cutting--Rough Trimming--Fine Trimming--Corner Rounding--Scraping--Buffing * Working
Voltage: 380V/50HZ /3PH * DELTA inverter or MCGS inverter for your choice. * PLC Touch Screen * CC highspeed motor. * The conveyor
speed can be adjusted from 13-25m/min *Honeywell travel switch, contactor, air switch. *Air Tac solenoid valve, air
cylinder,oil-water seperator. * With automatic oil feeder. *14mm high strenth steel sheet for the whole machine. * In the machine
is mounted lights. * Support customization for the machine appearance.
