Zhangjiagang Cedar SB-89CNC Fully Automatic Hydraulic Pipe Bending Machine Produced at China Price

Описание и отзывы

Трекер стоимости

Характеристики

Machine characteristics:
1. This model is an economical full-automatic three-dimensional CNC pipe bending machine, which can automatically bend, feed, and tilt automatically. The three-dimensional three-dimensional pipe can be automatically bent at one time. The motor and servo driver control the drive, the elbow shaft is controlled by the hydraulic value, and the auxiliary speed is adjusted by the flow regulating valve.
2. Both the feeding and tilting axes can be set through the computer to set the speed of 1-8 stages according to the actual workpiece situation. The pipe bending shaft adjusts the matching speed through a pressure regulating valve.
3. The electric control system adopts Japanese Mitsubishi brand controller, super large PLC, strong performance and good stability.
4. Equipped with 10.4 ″ color touch screen, man-machine interactive operation, easy to understand. All bend data can be input through touch screen.
5. The screen display text is equipped with Chinese and English, which can be switched. If you need other languages, you can choose to order.
6. Each pipe can be set with multiple bends (or selected by the user), and the memory capacity can store 330 (or 125) bend data (expandable).
7. After the data editing is completed, there is a key lock function to prevent the data from being modified arbitrarily.
8. With power-off memory function, the data can be saved permanently.
9. Can set manual, semi-automatic and fully automatic operation modes. You can choose to manually decompose the motion during the test bend, observe the interference point, and modify the motion.
10. Each axis can be set to feed, unbend, and rotate the tube in three axes to move together or differently to avoid interference points, thereby improving production efficiency. There are eight ways to choose from: one.Feeding → Backbend → Tilt; two. (Feeding + Backbend) → Tilt; three. (Feeding + Backbend + Tilt); four.Feeding → Tilt → Backbend; five. ( (Feeding + tilting) → Backbend; six.Backbend → Feeding → Tilt; seven. Tilt → Backbend → Feeding; eight. Backbend → (Feeding + Tilt).

FAQ

Choose us    Q: How to quickly choose the most suitable product for you?    A: You can check it on the product page, or contact customer service at +8618021646346 to tell the following details: What machine do you need? The size, thickness, material, and processing requirements of the workpiece, it is best to have a drawing of the workpiece, and we will provide a more professional machine according to your requirements.

Payment method    Q: What are your payment terms?    A: We support T/T, L/C, etc. TT, 30% in advance, and the balance 70% before shipment.

Delivery guarantee    Q: What is the delivery time?    A: Usually in stock, if you need to order fixtures and molds, we usually complete it within 7-15 working days. For customized products, please contact customer service to determine the exact time.

Use guarantee    Q: When I bought this machine, I didn't know how to use it. what do I do?    A: We will send English manuals, installation and operation videos with the equipment. If you still have questions, we can talk via phone, Whatsapp, WeChat and email.

Quality assurance    Q: How to ensure quality?    A: We have factories. We are industry experts and have been operating for more than 10 years. We always adhere to the policy of "high quality, all-round service".

Warranty service    Q: How long is the warranty period?    A: Within one year from the date of leaving the factory, if the part fails or is damaged (Due to quality problems, wearing parts are excluded), our company provides these parts for free.

Company visit    Q: How do we reach your company?    A: Our company is located in Zhangjiagang City, Jiangsu Province, near Shanghai. You can fly directly to PVG Airport or Shanghai Hongqiao Airport. Welcome to visit our company.
