The product description



We are one of the most excellent hydraulic tool manufacturers in China, our products are of high quality and low price, the customer's favorable rate is 100%, welcome to purchase.



Model	1 inch	2 inch	3 inch	4 inch	5 inch
output	10T	16T	18T	21T	21T
stroke(mm)	160	230	320	380	380
pipe wall thick(mm)	2-3.5	2.75-4.5	3.5-6	4-6	4-6
work scope(mm)	13-34	22-60	22-89	22-108	22-114
overall weight(kg)	20	50	98	149	197
material	ductile iron	ductile iron	ductile iron	ductile iron	ductile iron
configure mold	(1 inch): 13mm/16mm/19mm/22mm/28mm/34mm (2 inch): 22mm/28mm/34mm/42mm/48mm/60mm (3 inch): 22mm/28mm/34mm/42mm/48mm/60mm/75.5mm/89mm (4 inch): 22mm/28mm/34mm/42mm/48mm/60mm/75.5mm/89mm/108mm (5 inch): 22mm/28mm/34mm/42mm/48mm/60mm/75.5mm/89mm/108mm/114mm

DIE DIAMETER AND WALL THICKNESS
Reference Diameter	Pipe Wall Thickness Range	Conventional Name	Mold Specification
Φ13mm	1.5mm-4mm	2 point	1/4
Φ16mm	1.5mm-4mm	3 point	5/16
Φ19mm	1.5mm-4mm	3 point	3/8
Φ22mm	2.5mm-4mm	4 point	1/2
Φ28mm	2.5mm-4mm	6 point	3/4
Φ34mm	2.5mm-4mm	8point	1 inch
Φ42mm	2.5mm-4mm	1.25 inch	1-1/4 inch
Φ48mm	2.5mm-4mm	1.5inch	1-1/2 inch
Φ60mm	3.0mm-5mm	2 inch	2inch
Φ75.5mm	3.0mm-6mm	2.5 inch	2-1/2 inch
Φ89mm	3.5mm-6mm	3 inch	3 inch
Φ108mm	4.0mm-6mm	4 inch	4 inch
Φ114mm	4.0mm-6mm	5 inch	5 inch
Selection Method	1.According to their own needs to choose the diameter of the elbow,the corresponding standard die size selection pipe bender 2.If there is no corresponding mold,you kan choose a slightly larger size mold (such as 20mm,22mm mold) 3.Check whether the wall thickness is suitable according to the corresponding die size (the wall thickness can be 0.5 larger or 0.5 smaller)
Applicable Pipes	It is suitable for galvanized pipe welding,seamless steel pipe,water  pipe,iron pipe,wire guide pipe,gas pipe,steel pipe and aluminum pipe.It is not suitable for bending thin-walled pipe,steel pipe not conforming to bending outer diameter and non-ferrous metal pipe.
