Electrical single pole mcb breaker DZ47-63 mini

Категория: Circuit Breakers >>>
Поставщик: Foshan,Guangzhu,Electrical,Co.,Ltd.

Цена:42,37 ₽ - 74,33 ₽*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	50.94 $*	53.39 $*
Aug-15-2025	50.98 $*	53.58 $*
Jul-15-2025	42.91 $*	44.2 $*
Jun-15-2025	49.86 $*	51.71 $*
May-15-2025	42.12 $*	44.30 $*
Apr-15-2025	48.20 $*	50.4 $*
Mar-15-2025	47.81 $*	49.1 $*
Feb-15-2025	47.20 $*	49.98 $*
Jan-15-2025	47.21 $*	49.53 $*

Характеристики

Electrical single pole mcb breaker DZ47-63 mini circuit breaker

Main Specifications:

1. New design C63 circuit breaker

2. High breaking capacity: 6kA/10kA

3. Rated voltage:220V/400V

4. CE CB ISO9001

5. OEM,ODM service

6. Accept small order

C45 Ac 230/400v 63A Single Pole Mcb Mini Electronic Circuit Breaker

Product Description

_20210409170244

1).Rated current: 3,6,10,16,20,25,32,40,50,63A;

2).Tripping characteristics:B(3-5)In,C(5-10)In,D(10-15)In;

3).No. of pole:1P,2P,3P,4P

4).Breaking capacity: 6KA/10kA;

Standard		IEC60898,EN898
Number of poles		1P,2P,3P,4P
Rated current(In)		3,6,10,16,20,25,32,40,50,63
Rated voltage(Un)		AC 220/400V
Rated frequency		50Hz/60Hz
Tripping curve		C,D
Release action characteristics	Time delay	1.13In>1h Non-trip
		1.45In<1h trip
		2.55In 1s~60S trip
	Instantaneous(Curve C)	5In >0.1s Non-trip
	Instantaneous(Curve C)	10In<0.1s trip
Magnetic releases operate		B curve:between 3 and 5In
		C curve :between 5 and 10In
		D curve: between 10 and 15In
Ratedbreaking capacit(Lcn)		6000A
Endurance		>2500
Circumstance temperature		-5~+40
Electrical life		>6000times
Mechanical life		20000 times
Tropical ration		Treatmen 2(RH95%,at 55°C)
Protection degree		IP20

Application

Application:

This C63 circuit breaker is mainly used in AC50/60Hz single pole220V or two,three,four pole 400V voltage for overload and short-circuit protection as well as for unfrequent on-and-off switching electric equipment and lighting circuit under nrmal condition.

This C63 circuit breaker is suitable for industry, business, building, ressidence, etc.

This C63 circuit breaker is conformity with GB10963,IEC60898 standards.
