Type: ASME standard T50 20-foot LPG ISO tank container Design temperature: -40 degrees Celsius to +55 degrees Celsius Certificate: csc certificate, such as BV / LR
Logo:Customer's Logo
Port: Shanghai
Standard:ASME
Key Selling Points:Long Service Life
After Warranty Service:Video technical support, Online support
Applicable Industries:Food Shop, Energy & Mining, liquid storage tank
Marketing Type:New Product 2021
Keywords:Liquid Cylinders
Shape:Cylinder
Dimension(L*W*H):customized
Description and Specification of Commodity
Overall Size
6058*2438*2591/mm
Compartment
single
Painting
Complete chassis sand blasting to clean rust,1 coat of anti-corrosive prime,2 coats of final paint
Design data sheet
Code and Regulations
ASME BOILER AND PRESSURE VESSEL CODE,SECT.VIlI.DIV.2 WITH U2-STAM
RID/ADR,IMDG
DESIGN PRESSURE(MPa)
1.52
PRESSURE-RETAINING
Shell
SA-612M NORMALIZED
MAWP,acc IMDG(MPa)
|1.38
PARTS
Heads
SA-612M NORMALIZED
MEAWP(MPa)
0.1
EXTERNAL DEMENSIONS(L/W/H)
6058/2438/2591
DESIGN TEMPERATURE(℃)
55
INSULATION OR SUN SHIELD
SUN SHIELD
OPERATING TEMPERATURE(℃)
-40~50
Paint
Frame
30um+40um+50um
MDMT(℃)
-40
Shell
30um+40um+50um
NOMINAL VOLUME(L)
25000
MAX.GROSS MASS(KG)
350004
FILLING MEDIUM
1,1,1,2-Tetrafluoroethane
TARE MASS(KG)
6800
MEDIUM UN NUMBER
UN3159
MAX.FILLING DENSITY (t/m3
1.04
TANK INSTRUCTION
T50
MAX.PAYLOAD(KG)
22568
CORROSION ALLOWANCE(mm)
0
JOINT EFFICIENCY(SHELL/HEAD)
1
PWHT(YES/NO)
YES
TEST
HYDRO.TEST PRESSURE(MPa)
2.18
U2 STAMP
YES
LEAKAGE TEST PRESSURE(MPa
1.38
INSPECTION AUTHORITY
BV/TUV
N/A
N/A
Our factory with more than 20 years' experience. Being famous in domestic and foreign countries, we concentrate on tank container and trailer's research and development. Our aim is to provide high quality and low price products for the customer. Experienced and technological team customize the best productions for customers. For any reliability& safety and economic related questions, we all have mature solutions at any time.
Henan Lishixin Logistics Equipment Co., Ltd is located in Zhengzhou FTA,Henan Province, China, with a registered capital of 3, 500, 000USD.Lishixin is specialized in the R & D, mass production and sales of kinds of the 20FT, 30FT, 40FT ISO Storage Tank Containers and Storage Tanks as well as other special logistic Transportation equipments.Based on rich transportation advantages and resource of Central China, Lishixin is committed to supply high quality and cost-effective transportation equipment for clients all over the world.
Main Products: ISO storage tank containers(Liquid tank containers,Powder Tank containers, Cryogenic tank containers, CNG Tank Container, Cryogenic Liquid Gas Storage Tanks), Cryogenic Tank Semi Trailer etc. Other logistic transportation equipments.
International Market: Annual production capacity 8000units of the Tank Containers,and the annual total sales 3500units, Of which, we have exported more than 800units Tank containers, Cryogenic Tank Semi Trailer to more 25 countries around the world, including Mexico, Columbia, Chile, Peru, Honduras, South African, Nigeria, Egypt, Algeria, Saudi Arabia, Turkey, Pakistan,Myanmar, Uzbekistan, Russia, Ukraine, Philippines,Indonesia, Malaysia, Bangladesh, etc. What's more, we have established long-term semitrailer&tanks supply contracts with more than 10 famous transportation&other type of the enterprises in the world.
Q:What kind of Payment can you accept?
A:T / T and L/C is all right to us.
Q:Does your iso tank container meet with international requirement?
A:All of our tank container will be approval by BV or LR or CCS and meet with International Standard.
Q:How long will it takes to ship?
A:Around 15-25 working days.
Q: How about the Color , Specific configuration things?
A:It's up to you , most of them are optional and can be changed by your needs.
Q: Are the LPG tank containers you sell brand new? A:Yes, all the containers we provide are brand new. In fact, we will produce new containers after the order is confirmed. Q: Does the iso tank container you sell meet international requirements? A:All our tank containers will be approved by BV or LR or CCS. Q:Can you provide drawings for confirmation? A:Yes, we will provide drawings after confirming the order before production Q:Do you have a small-capacity or a large-capacity tank container? A:Of course, we can make Tank Containers from 1000L to 60000L. Q: Do you provide OEM service? A:Yes, we have a first-class team that can design according to your requirements.
If you are interested in our products, please do not hesitate to contact us.
