Характеристики
24 in 1 H.265 HDMI Low Bitrate 4k IPTV encoder
Product Description
1.Design good for indoor usage.
2.4 satellite IF+1 Terrestrial input for 16 satellite receivers.
3.Built in Amplifiers.
4.Ideal for middle or large SMATV systems.
Specification
Model: | SH516ET | ||||
Frequency | Satellite: | (MHz) | 950-2150 | ||
Terrestrial: | (MHz) | 47-862 | |||
Inputs (F Connectors) | 4 Sat.+1 Terr.+ Power In | ||||
Outputs (F Connectors) | 16Taps | ||||
Gain | Tap Sat. | (dB) | 15 | ||
Tap Terr. | (dB) | 15 | |||
Gain Adj. | Inputs | (dB) | 10 | ||
Isolation | Trunk-Trunk | (dB) | 28 | ||
Cross Polar | (dB) | 25 | |||
Tap-Tap(Sat) | (dB) | 25 | |||
Tap-Tap(Terr.) | (dB) | 23 | |||
Rejection | (dB) | 20 | |||
Return Loss | Trunk in/out | (dB) | 10 | ||
Tap | (dB) | 8 | |||
Output Level | Sat.(IMA335dB)EN50083-3 | (dB) | 100 | ||
Terr.(IMA360dB)EN50083-5 | (dB) | 85 | |||
Switching Voltage (V) | 15+1V | ||||
Power Adapter | IN:100~240V OUT:18V 2A | ||||
Dimensions (L,W,H) (mm) | 280×125×43 | ||||
Related Products
Packing&Shipping
Package type: each pcs wth soft ,safety polyfoam ,then packed in brown box
Shipping way: it usually take 5-7 days by DHL, TNT, Fedex, UPS to arrive your local place
