The double shredder machine adopts two double shafts individual drive,so during production ,make the material produce homologous's squeezed ,that reach mechanical feed function,special cutter shaft structure and quadrangle rotary type tool,in the low speed and high torque's production process,won't appear wind shaft or jammed devices ,thus improve the production efficiency,the equipment is suitable for crushing various materials with high toughness and viscosity.
Processing flow of Wood shredder pallet machine
Description: Wood shredder pallet machine is especially suitable for the crushing of those very-large and ultra-thick objects.(such as tyres, supporting boards, packing barrels, which are usually difficult to break).
Features: 1) The shredder have the characteristics of strong crushing ability, low noise, environmental- friendly. 2) The motor connected with the shaft directly, it can avoid belt slipping and avoid the easy wear part broken. 3) Compact structure. The motor is directly connected to the shaft roller, wshich can avoid slipping and spare parts broken. 4) The spare parts are made of high manganese steel which is of high reistance.
Working Principle The materials are fed into through feed inlet. With a high speed of rotation, the blade knifes could peel and cut the materials. And then the materials are sent out through high speed steam-flow produced by fan blade in the knife plate.
Technical parameter of Wood shredder pallet machine
:
Model
420
500
700
800
1000
1200
1500
1800
Blade
(sheet)
4
4
4
4
4
4
4
4
Feed diameter
(mm)
150*150
180*200
230*230
250*250
270*270
330*330
420*400
520*520
Spindle speed
(r/min)
2600
2600
2400
2000
2000
1500
1200
1200
Motor
(kw)
7.5/11
18.5
37
45/55
45/55
75/90
110/132
132/160
Diesel engine
(horsepower)
18
28
50
80
80
120
160
200
Yield
(kg/h)
300-500
500-600
800-1500
1200-2000
1500-3000
3000-7000
3000-10000
3000-12000
Weight
(kg)
280
380
520
750
1080
1280
3100
38
The application of the Small Metal shredder machine car crusher: 1.Shred the unqualified product into smaller pieces for recycling. 2.Reduce the volume of raw raw materials for mixing with other materials. 3.Shredding organic matter to make biofuel. 4.Shred some textile materials to facilitate the recycling of the fibers, such as the smashing of the carpet.
