Thrust roller bearings are separable bearings, can only withstand axial load and a slight impact, to limit the shaft (or shell) of the axial displacement in one direction, it can be used as single-axis to the position. But its carrying capacity is far greater than the thrust ball bearings.
292xx
293xx
294xx
The single direction thrust ball bearing consist of a shaft washer, a housing washer and a ball and cage thrust assembly.
The bearings are separable so that mounting is simple as the washers and the ball and cage assembly can be mounted separately.
The types: bearings with a flat seat surface on the housing washer, bearings with a sphered seat surface and bearings with a sphered housing washer can be used together with a sphered seat washer.
This type bearing can accommodate axial loads in one direction and thuslocate a shaft axially in one direction. They must not be subjected to any radial load.
Thrust Roller Bearings are used for axles of axial load and radial joint load, but the radial load shall not exceed 55% of axial load. Compared with other thrust roller bearings, such bears are provided with lower friction coefficient, higher speed and self-aligning properties.The rollers of these bearings are of spherical shape, and the spherical raceway surface of the housing washer is self aligned.
Features
Spherical roller thrust bearings are featured by the extremely big axial load carrying capacity and meanwhile they can also carry cetrain radial load.
Typical application
Applications of these bearings can be found in steel industry, mining&construction, papermaking machinery, gearboxes, injection molding machines, motorcycles, crane hooks, pump, centrifuge, jack, speed reducer.
Specification
item
value
Type
Roller
Structure
Thrust
Applicable Industries
Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Construction works , Energy & Mining, Other
Brand Name
ROWISS
Model Number
29322
Precision Rating
P0 P2 P4 P5 P6
Seals Type
Open
Number of Row
Single Row
Place of Origin
China
Product name
Spherical Roller Thrust Bearings
Hardness
HRC58-62
Material
Chrome Steel GCR15
Cage
Brass Cage Steel Cage
Feature
Heavy Loading Duty
Service
OEM Service.Design Service
CLEARANCE
C0 C2 C3 C4 C5
Quality
ISO Standard
Sample
Avaliable
Deliver time
3-15 days
Packing & Delivery
1.Industrial packing+carton box+pallet
2.Single box+carton box+pallet
3.Packing as per customers' request
