Месяц | Минимальная цена | Макс. стоимость |
---|---|---|
Sep-18-2025 | 236.59 $* | 248.85 $* |
Aug-18-2025 | 234.66 $* | 246.51 $* |
Jul-18-2025 | 196.30 $* | 206.3 $* |
Jun-18-2025 | 230.46 $* | 242.47 $* |
May-18-2025 | 200.71 $* | 210.81 $* |
Apr-18-2025 | 226.59 $* | 237.56 $* |
Mar-18-2025 | 224.76 $* | 235.94 $* |
Feb-18-2025 | 222.91 $* | 233.44 $* |
Jan-18-2025 | 220.7 $* | 231.39 $* |
Model No. | MQ1 |
Rated voltage | 220 - 240V (single phase) / 380 - 400V (3 phase) |
Rated power | 12kW - 24kW |
Heating element | Patented aluminum die-cast heating plate |
Cover | Metal enclosure with electrostatic powder coating |
Operation mode | Electronic touch panel |
Hot water capacity | Endless |
Water temperature control | Constant (±0.5℃) |
Protection against electric shock | Class 1 |
Degree of ingress protection | IP25 |
Starting flow rate | 1.2 L/min. |
Hot water flow rate | 8 - 15 L/min. (2.1 - 4.0 GPM) |
Product size | 360mm x 565mm x 180mm |
Gross weight | 8.6kg |
Model | MQ1 | ||||||||||||
Reference No. | 120 | 140 | 160 | 180 | 200 | 220 | 240 | ||||||
Intended application A | 1B+1S | 1B+2S | 2B+1S | 2B+2S | 3B+1S | 3B+2S | 3B+3S | ||||||
Rated power | 12kW | 14kW | 16kW | 18kW | 20kW | 22kW | 24kW | ||||||
Rated frequency | 50 / 60Hz | ||||||||||||
Rated current | 18.2A | 21.3A | 24.3A | 27.3A | 30.4A | 33.4A | 36.4A | ||||||
Circuit breaker | 25A | 25A | 32A | 32A | 40A | 40A | 63A | ||||||
Recommend wire | 5 x 2.5mm2 | 5 x 4mm2 | 5 x 6mm2 | ||||||||||
Water temperature | 32℃ - 55℃ | ||||||||||||
Rated water pressure | 0.03-0.6MPa | ||||||||||||
Max. water pressure | 0.8MPa | ||||||||||||
Starting flow rate, GPM | 0.3 | ||||||||||||
Max. flow rate, GPM B | 2.1 | 2.5 | 2.8 | 3.0 | 3.3 | 3.6 | 4.0 | ||||||
Inlet/outlet connection | G 3/4 BSP pure brass connector |
