Setlcom 58mm Mini Portable Thermal Printer Android

Printing method

Line thermal printer

Printing speed

90mm/s

Dot pitch

8dots/mm, 384 dots/line

Printing width

48mm

Paper width

57.5±0.5mm

Paper roll outer diameter

40mm (Max.)

Paper roll inner diameter

13mm(Min.)

Paper thickness

60-80um

Overall dimension(WxDxH):

79x110x45mm

Weight ( g)

210(non- including the paper roll)

Printing characters

ANK: 8x16,9X17, 9x24,12x24  GBK:24x24

Characters/line

ANK:48, 42, 32   GBK:24, 16

Life cycle time

50km(printing density under 12.5%)/100 million pulses

Barcode type

1D: UPC-A,UPC-E,EAN-13,EAN-8,CODE39,CODE93,

CODE128,CODEBAR,ITF25

2D: QR CODE, PDF417

interface

Bluetooth V2.1 CLASS (V4.0 Developing) CLASS ,RS232,USB

RS232, USB

Power

1500mAh 7.4V  rechargeable Lithium battery

Recharge adapter

Stand by recharging / AC adapter

Black mark test

Supported

Paper feeding

Easy paper loading

Paper cut

By hands

commands

ESC/POS compatible with order sets

operate setting

Temperature -10°C~50°C ; Humidity 20%~85%

Recharge Setting

Temperature 5°C~40°C; Humidity 20%~85%

Storage Setting

Temperature -20°C~70°C ; Humidity 5%~95%

Standard accessories

li-ion battery, AC adapter, USB interface cable, Long-term preservable paper, user manual

Optional accessories

Serial interface cable/CD/Car charger
