Product Description
h type broiler cage/chicken cage equipment
(1)Tiers:3,4, leves/floors
(2)Material:Q235 Hot-Dipped Galvanized,Zinc thickness: 275g/㎡
(3)Frame:Material of leg of frame is hot-dip galvanized steel with thickness: 2mm
(4)Feed trough:Material: hot-dip galvanized steel. Thickness: 1.0mm.
(5)Design:Fully Automatic Poultry Broiler Chicken Cage Equipment
(6)Fully Automatic System Including Meat Chicken Farm Broiler Chicken Poultry Battery Cages Body,Broiler Bird Chicken Cage Frame,Feeders,automatic drinking system,on-rail hopper feeding system,manure removal stystem,chicken harvesting system,Ventilation System etc
Automatic On-Rail Hopper Feeding Machine Equipments
1.Hopper:Each tier with two hoppers, thickness is 1.2mm, material is hot-dip galvanized steel
2.Traction Device :Power of motor:0.75kw,tow rope: pp rope with 14mm,speed:8.67m/minute.
3.Track of Trolley:Hot-dip galvanized steel with 48mm*2.75mm.
4.Head and end frame:Hot-dip galvanized steel with 40mm*60mm*3mm.
Silo&Feed Uploading Machine Equipments
1.Capacity:4tons,8tons,10tons,13tons,15tons,20tons,33tons
2.Thickness:3mm thickness hot galvanized steel
3.Feed density0.65ton/m3.Material of silo is galvanized steel (275g) ,which is anti-erosive and ensures the long service life
4.Feed weighing device can be installed if required to control the feed amount consumed by layers
5.Auger Feed Uploading Device:Hot-Dipped Galvanized
Plastic Slat/Floor
1.Material:Polypropylene,good flexibility
2.Use:Floor can be pulled out when catching the chicken
Large Living Space&Large Door
Advantage:Easier to catch the birds if in manual way;And helps birds live comfortably and grow heathily
Space between two levels of cages
650mm/800mml;
Advantage:Better air circulation to reduce the diease
Nipple Drinkers&Water Pipes
1.Water flow: 30-40ml
2.No water splashing or leaking, the bird house is dry and clean.
3.25mm*2mm PVC round pipe,resistance 90°bending with seven times.
Automatic Manure/Waste Cleaning Machine Equipments
1.Belt type manure cleaning machine:Hot-dip galvanized 3mm side plate,chain safety door with 1mm hot-dip galvanized steel, running speed 3m/min.1.5KW
2.Manure cleaning belt:Material is PP, which has high tensile strength to ensure a long service life.Thickness is 1.2mm.Width is 1.2m.
3.Bracket for manure cleaning belt:Material is hot-dip galvanized steel, thickness is1.5mm.
Crosswise Manure/Waste Conveyor
Transverse manure conveying :
Each house is with 1 set, transverse and slope conveying is separate, the material is 5mm angle steel welded.
Manure belt: rubber belt with 8mm thickness.
The transverse manure conveying system adopts rubber conveying belt. There is no leak of manure during the transportation.
Manure belt: rubber belt with 8mm thickness.
The transverse manure conveying system adopts rubber conveying belt. There is no leak of manure during the transportation.
Ventilation Fans
1.Fan frame: Hot-dip galvanized steel with Zinc thickness 275g/m2.
2.Blade: 430BA stainless steel with 1.2mm thickness sheet.
3.50"Fans
Size:1380x1380x450mm
Airflow:44000m3/h
380V/ 50HZ /1.1KW
Cooling Pad
1.Thickness:150,200mm
2.Length:1500,1800,2000,2500mm or as customers' request
3.Frame:Galvanized Or Aluminimum
4.Water Recycling System Included
Environmental Controller
EC-1211 Environmental Controller
1.Box Size:305x228x120mm
waterproof box
2.Multi-functions
3.High quality and application
Roof Fans
1.Diameter:80cm
2.Material:Stainless Steel
3.Application:Poultry House
4.No electricity need,no noise,can work in the long way.
Specification
Automatic Chicken Harvesting H Type Farm Equipments for Broilers | Manual Chicken Harvesting H Type Farm Equipments for Broilers | ||||||
Material | Hot Dip Galvanized Steel | Material | Hot Dip Galvanized Steel | ||||
Tiers | 3 or 4 Tiers | Tiers | 3 or 4 Tiers | ||||
Capacity | 156 birds or 208 birds | Capacity | 96 birds or 128 birds | ||||
Size | 1480mm*1750mm*440mm | Size | 1300mm*1250mm*430mm | ||||
Area of per Chicken | 498cm2 | Area of per Chicken | 508cm2 | ||||
Automatic Chicken Harvesting
H Type Meat Broiler Raising Chicken Cages Plan
Manual Chicken Harvesting
H Type Meat Broiler Raising Chicken Cages Plan
Company Profile
HENAN SILVER STAR POULTRY EQUIPMENT CO.,LTD, having a production history of more than 20years.Our company has the ability of producing more than 30 kinds of products.Our production line,from wire drawing, straightening,welding,forming to galvanization,has already been formed. As a result,production is running smoothly,At the moment,our company can produce whole supporting equipment.Since our products entered the market,our products have won the praise of consumers and professionals from all walks of life and become the leading industry-recognized products in China.Through years of practice and exploration,our products are tight,flexible and durable,Our clients all over the world.
Our Projects
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Our Certificate
Quality&Warranty
Quality:We assure of our product quality life span at least 15 years.
Warrenty:According to international rules,product given one year warrenty.
QUALITY &SERVICE ARE ALWAYS OUR PERSUIT.
Refuse product bad quality!
Warrenty:According to international rules,product given one year warrenty.
QUALITY &SERVICE ARE ALWAYS OUR PERSUIT.
Refuse product bad quality!
After-Sales Service
If customer have installation request,we will send one or two or more engineers for supervision of the installation, commissioning
and training .But the buyer shall pay installation cost,round ticket fees,accomodation fees,insurance etc related charges.
Besides,we have quality assurance,if unartificial product prolem,please feel free to contact us,we will send u for free.
and training .But the buyer shall pay installation cost,round ticket fees,accomodation fees,insurance etc related charges.
Besides,we have quality assurance,if unartificial product prolem,please feel free to contact us,we will send u for free.
Why Choose Us?
2..We consider completely from the customer demands, research and development products focus on energy saving, economic, practical and convenient, also make risk assessmenton the rate of investment return;
3.Owning professional technical and service team, being able to answer customers’ questions in 24 hours online;
4.Main Product--Chicken Cage.National standard bridge steel raw material;
5.Use Service Life:Mora than 25 years and Assured;
6.Our company has the right to import and export, the products are exported to more than 30 countries around the world,has been one of the export leading enterprises in this line.
