30 кВт постоянного и переменного тока многофункциональное быстрое зарядное устройство wallbox ev ccs
- Категория: Wall-mounted Charging Stations >>>
- Поставщик: Guangzhou,Electway,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 6545.76 $* | 6872.99 $* |
| Aug-19-2025 | 6490.55 $* | 6815.31 $* |
| Jul-19-2025 | 5445.56 $* | 5717.1 $* |
| Jun-19-2025 | 6380.53 $* | 6699.95 $* |
| May-19-2025 | 5555.4 $* | 5833.53 $* |
| Apr-19-2025 | 6270.33 $* | 6584.80 $* |
| Mar-19-2025 | 6215.28 $* | 6526.41 $* |
| Feb-19-2025 | 6160.37 $* | 6468.94 $* |
| Jan-19-2025 | 6105.34 $* | 6410.85 $* |
Характеристики
Product Overview
China factory 30kw dc fast car charger wallbox ev charger with chademo ccs conncetor ocpp rfid charger
PRODUCT SPECIFICATIONS
AC input | ||
Input rating | 380VAC±15% | |
Ac input connection | 3P+N+PE | |
Max.input current | 50A@380V | |
Power factor | >0.99@full load | |
Efficiency | 95% | |
Frequency | 50/60Hz | |
DC output | ||
Output Voltage range | 50-500VDC | |
Max.Output Power | 30kw | |
Max.Output current | 80A@375V,30A@1000V | |
User Interface | ||
HMI | 7’touch display(Android),RFID | |
Push Buttons | Emergency stop | |
Communication | VPN/DNS/Cloud,Wi-Fi,RJ45,Router3/4G(GSM or CDMA),Modbus TCP,PLC | |
Packing | 160*74*31cm,80KG | |
Environmental | ||
Temperature | -20℃ - +50℃,power derating from +50℃ and above | |
Humidity | 5%-90%RH,non-condensing | |
Altitude | 2000m | |
IP level | IP54,IK10 | |
Mechanical | ||
Cable Length | 5M(CHAdeMO),5M(CCS),5M(GB/T)Customized acceptable | |
Regulation | ||
Standard | EN61851-1,JEVSG105 | |
Certification | CE,ROHS,IEC | |
Protocol | CHAdeMO2.0/DIN70121,OCPP1.6(JSON or SOAP),ISO15118 | |
Noise Level | <50dB in all direction | |
Customer feedback
The features for wall mounted DC&AC charger:
1. Mobile charging with up to 200km/h.
2. The CHR-30 quick charger was developed for electric vehicles with CHAdeMo or CCS Combo DC charging sockets and is designed for
semi-mobile use.
3. It is compatible with all popular industrial sockets and can be used with CEE63 plug sockets.
4. The charger is flexible in use thanks to its compact dimensions and is especially suitable for use with vehicle pools,i
workshops or at motoring events.
1. Mobile charging with up to 200km/h.
2. The CHR-30 quick charger was developed for electric vehicles with CHAdeMo or CCS Combo DC charging sockets and is designed for
semi-mobile use.
3. It is compatible with all popular industrial sockets and can be used with CEE63 plug sockets.
4. The charger is flexible in use thanks to its compact dimensions and is especially suitable for use with vehicle pools,i
workshops or at motoring events.
