Грузовик с воздушной платформой Marilyn DONGFENG DKL
US $12000-$29900
Высококачественная Мобильная подъемная платформа с шарнирным
- Категория: High-altitude Operation Trucks >>>
- Поставщик: Evangel,Industrial,(Shanghai),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 23800.8 $* | 24990.54 $* |
| Aug-19-2025 | 23600.78 $* | 24780.48 $* |
| Jul-19-2025 | 19800.45 $* | 20790.53 $* |
| Jun-19-2025 | 23200.59 $* | 24360.40 $* |
| May-19-2025 | 20200.42 $* | 21210.77 $* |
| Apr-19-2025 | 22800.18 $* | 23940.22 $* |
| Mar-19-2025 | 22600.71 $* | 23730.40 $* |
| Feb-19-2025 | 22400.83 $* | 23520.52 $* |
| Jan-19-2025 | 22200.5 $* | 23310.51 $* |
Характеристики
20m articulated mobile elevating work platform features compact composition, obstacle-crossing, precise control, powerful driving
and easy operation. The machine is simple, efficient, safe and reliable, meeting demands of users from building construction,bridge and equipment maintenance, shipyard and petrochemical industry and users from rental service.
Advantages and highlights:
* Upwards, downwards and crossed multi-directional precise position and excellent extension
* The electrical system makes use of the distributed PLC-control technologies and the proportional valve being of self-adaptation method, leading the products in the terms of adaptability.
* Full-hydraulic drive, turntable free slewing by 360°, limitless angle in full work range, easy operation, reliable.
* 4WD drive, off-road wide tires and axle-balancing device enable the machine to be excellently suitable for any terrain, with grade ability up to 45% ranking the top in industry.
* The complete vehicle is compact. Before transportation, the crank is retracted back, shortening the transportation length to only 7m.
* Zero tail swing design could facilitate the entering of narrow room and the storage.
and easy operation. The machine is simple, efficient, safe and reliable, meeting demands of users from building construction,bridge and equipment maintenance, shipyard and petrochemical industry and users from rental service.
Advantages and highlights:
* Upwards, downwards and crossed multi-directional precise position and excellent extension
* The electrical system makes use of the distributed PLC-control technologies and the proportional valve being of self-adaptation method, leading the products in the terms of adaptability.
* Full-hydraulic drive, turntable free slewing by 360°, limitless angle in full work range, easy operation, reliable.
* 4WD drive, off-road wide tires and axle-balancing device enable the machine to be excellently suitable for any terrain, with grade ability up to 45% ranking the top in industry.
* The complete vehicle is compact. Before transportation, the crank is retracted back, shortening the transportation length to only 7m.
* Zero tail swing design could facilitate the entering of narrow room and the storage.
Item | Unit | Parameter |
Overall length of complete machine | mm | 9080 |
Overall width of complete machine | mm | 2490 |
Overall height | mm | 2680 |
Wheelbase | mm | 2500 |
Max. working height | m | 20.4 |
Max. platform height | m | 18.4 |
Max. working range | m | 11.9 |
Max. carrying weight | kg | 230 |
Scope of luffing of No.1 arm | ° | 0~+70 |
Scope of luffing of Boom No.2 | ° | 0~+75 |
Crank arm luffing range | ° | -65~70 |
Slewing angle of turntable | ° | 360 |
Max. Tail swing | mm | 0 |
Dimension of platform | mm | 1830×760×1150 |
Slewing angle of platform | ° | 160 |
Overall weight | kg | 10600 |
Max. traveling speed | km/h | 6 |
Min. turning radius | m | 6 |
Min. ground clearance | mm | 230 |
Max. gradeability | % | 45 |
Specification of tire | 355/55D625 | |
Engine model | Perkins 404D-22 | |
Engine rated power | kW/(r/min) | 38/(3000) |
