Easy To Operate 320 Ton Mining Dump Truck XDE320 Heavy Duty Tipper Truck For Sale





Main Features:

1. It carries an imported genuine electronic control diesel engine, single-stage turbo charging, which is fuel economic and powerful; engine monitoring system can continuously detect cylinders working conditions, which can help prolong engine service life and reduce cost of use.


2. Imported alternating current drive system is adopted for the truck, makings it safe and reliable, lowering failure rate and reducing maintenance cost; and this system can realize constant power control and stepless speed regulation, offers strong traction and ensures maximized productivity.


3. The truck has a box-section design and is made of high-quality alloy steel plates, which gives it anti-fatigue strength, low-temperature impact resistance and good welding performances. Crucial stress-bearing positions are made of steel casts, which extend the service life.


4. Wagon is welded by high-strength anti-wear plate and low-alloy high-strength quenched and tempered steel, which ensures a long service life; a lightweight design can largely reduce wagon weight, improve transportation efficiency and reduce fuel consumption.


5. ROPS & FOPS that meet ISO standards are installed for driver's cab, and its ergonomic design enlarges interior space, broadens field of view range, secures driver's working safety and increases comfort level of driving experience.

Product Specifications:

Item		Unit	XDE320
Performance parameters	Rated Payload	t	320
	Empty Weight	kg	210000
	Gross Vehicle Weight	kg	510000
	Drive Style		4x2
	Max. Speed	km/h	64.5
	Max. Gradeability	%	18
	Min. Turning Diameter	m	30.8
	Overall dimension	mm	15310*8930*7380
Engine	Model		16V4000
	Rated Power/Speed	kW/rpm	2014/1800
	Max. Torque/Speed	Nm/rpm	11310/1700
Electric drive	Alternator		GTA41B
	Traction Motor		GDY114
	Ratio		32.62:1
Tires	Standard Tire		53/80R63
