Тяжелая стрела 70 тонн для нефтяных месторождений и шахт
- Категория: Truck Cranes >>>
- Поставщик: Oriemac,Machinery,&,Equipment,(Shanghai),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 117810.36 $* | 123701.67 $* |
| Aug-19-2025 | 116820.45 $* | 122661.67 $* |
| Jul-19-2025 | 98010.56 $* | 102911.44 $* |
| Jun-19-2025 | 114840.38 $* | 120582.37 $* |
| May-19-2025 | 99990.38 $* | 104990.35 $* |
| Apr-19-2025 | 112860.84 $* | 118503.79 $* |
| Mar-19-2025 | 111870.9 $* | 117464.62 $* |
| Feb-19-2025 | 110880.48 $* | 116424.62 $* |
| Jan-19-2025 | 109890.3 $* | 115385.51 $* |
Характеристики
Heavy-duty 70 tons boom crane for lifting project XCT70_S
- Maximum rated lifting capacity(t)70
- Fully-extended boom(m)44.5
- Engine rated power(KW/rpm)268/1900
| Category | Item | Unit | Parameter | |
| Dimensions | Outline size(lengthxwidthxheight) | m | 14700x2790x3820 | |
| Wheel base | m | 1470+4500+1350 | ||
| Track(Front/ Rear) | m | 2353/2325 | ||
| Front/ Rear overhang | mm | 2380/2450 | ||
| Front/ Rear extension | mm | 2045/505 | ||
| Weight | Total vehicle mass in travel configuration | kg | 44800 | |
| Axle load | 1st axle | kg | 9450 | |
| 2nd axle | kg | 9450 | ||
| 3rd axle | kg | 12950 | ||
| 4th axle | kg | 12950 | ||
| Power | Engine model | D10.38-50 | ||
| Engine rated power/rpm | kW/(r/min) | 268/1900 | ||
| Max. net power/rpm | kW/(r/min) | 274/1900 | ||
| Engine rated torque/rpm | N.m/(r/min) | 1560/1200-1500 | ||
| Travel | Max. travel speed | km/h | ≥90 | |
| Min. travel speed | km/h | 1.7~3 | ||
| Min. turning diameter | m | ≤24 | ||
| Min. turning diameter at boom tip | m | ≤25.2 | ||
| Min. ground clearance | mm | 307 | ||
| Approach angle | ° | 19 | ||
| Departure angle | ° | 13 | ||
| Braking distance (at 30 km/h ) | m | ≤10 | ||
| Max. grade ability | % | 41 | ||
| Fuel consumption per 100 km | L | 43 | ||
| Main performance | Max. total rated lifting capacity | t | 70 | |
| Min. rated working radius | m | 3 | ||
| Turning radius at turntable tail | Counterweight | mm | 4350 | |
| Auxiliary winch | mm | 4545 | ||
| Max. load moment | Base boom | kN.m | 2812 | |
| Fully-extended boom | kN.m | 1622 | ||
| Fully-extended boom + Jib | kN.m | 554 | ||
| Outrigger span | Longitudinal | m | 6.545 | |
| Lateral | m | 7.9(5.6) | ||
| Hoist height | Base boom | m | 12.7 | |
| Fully-extended boom | m | 48.5 | ||
| Fully-extended boom + Jib | m | 64.5 | ||
| Boom length | Base boom | m | 12.4 | |
| Fully-extended boom | m | 48 | ||
| Fully-extended boom + Jib | m | 64 | ||
