Характеристики
Product Description
Product Name | PSA oxygen generator | ||||||
Model No. | XSO- 5/10/20/40/60/80/CUSTOMIZED | ||||||
Oxygen Production | 5~200Nm3/h | ||||||
Oxygen Purity | 70~93% | ||||||
Oxygen Pressure | 0~0.5Mpa | ||||||
Dew Point | ≤-40 degree C | ||||||
Specification
Specification | Output (Nm3/h) | Effective gas consumption ( Nm3/h ) | Air cleaning system |
XSO-5 | 5 | 1.3 | CJ-2 |
XSO-10 | 10 | 2.5 | CJ-3 |
XSO-20 | 20 | 5 | CJ-6 |
XSO-40 | 40 | 9.5 | CJ-10 |
XSO-60 | 60 | 14 | CJ-20 |
XSO-80 | 80 | 19 | CJ-20 |
XSO-100 | 100 | 22 | CJ-30 |
XSO-150 | 150 | 32 | CJ-40 |
XSO-200 | 200 | 46 | CJ-50 |
1. The first cryogenic 50m3 cryogenic oxygen production equipment in Ethiopia
50 cubic meters of cryogenic oxygen was shipped to Ethiopia in December 2020. The equipment, the first of its kind in Ethiopia, has already arrived in the country. Under construction and installation.
2. PSA oxygen generator
various oxygen suppliers in Peru asked our company to purchase several PSA oxygen generators and oxygen cylinders.
3. Workshop
Our precision designing makes our industrial gas systems reliable and efficient resulting in low operational costs. Being manufactured with high quality materials and components, our liquid oxygen plants lasts for a very long time requiring minimum maintenance. For our compliance with strict quality control measures, we have been awarded with acclaimed certifications like ISO 9001，ISO13485 and CE.
Working Principle
We manufacture PSA oxygen plant using the latest PSA (Pressure Swing Adsorption) technology. Being the leading PSA oxygen plant manufacturer, it is our motto to deliver oxygen machinery to our customers that is at par with international standards and yet is very competitively priced. We use premium quality materials bought from the best suppliers in the industry. Oxygen generated in our PSA oxygen generator meets the requirements of industrial as well as medical applications. Numerous companies from around the globe are using our PSA oxygen plant and are generating oxygen on-site for running their operations.
Our oxygen generator is also used in hospitals because the installation of oxygen gas generator on-site helps the hospitals to produce their own oxygen and stop their dependency on oxygen cylinders bought from the market. With our oxygen generators, the industries and medical institutions are able to get uninterrupted supply of oxygen. Our company uses cutting-edge technology in the making of the
oxygen machinery.
Our oxygen generator is also used in hospitals because the installation of oxygen gas generator on-site helps the hospitals to produce their own oxygen and stop their dependency on oxygen cylinders bought from the market. With our oxygen generators, the industries and medical institutions are able to get uninterrupted supply of oxygen. Our company uses cutting-edge technology in the making of the
oxygen machinery.
Salient features of PSA oxygen generator plant
Fully automated- systems are designed to work unattended.
PSA plants are compact taking little space, assembly on skids, prefabricated and supplied from factory.
Fully automated- systems are designed to work unattended.
PSA plants are compact taking little space, assembly on skids, prefabricated and supplied from factory.
Quick start-up time taking only 5 minutes to generate oxygen with desired purity.
Reliable for getting continuous and steady supply of oxygen.
Durable molecular sieves that last around 12 years.
Durable molecular sieves that last around 12 years.
Technical Characteristics
1.Full low pressure positive flow expansion process
2.Full low pressure back flow expansion process
3.Full low pressure process with booster turbo expander.
1.Full low pressure positive flow expansion process
2.Full low pressure back flow expansion process
3.Full low pressure process with booster turbo expander.
Advantage
1.Simple installation and maintenance thanks to modular design and construction.
2.Fully automated system for simple and reliable operation.
3.Guaranteed availability of high-purity industrial gases.
4.Guaranteed by the availability of product in liquid phase to be stored for use during any maintenance operations.
5.Low energy consumption.
2.Fully automated system for simple and reliable operation.
3.Guaranteed availability of high-purity industrial gases.
4.Guaranteed by the availability of product in liquid phase to be stored for use during any maintenance operations.
5.Low energy consumption.
6.Short time delivery.
Recommend Products
PSA NITROGEN GENERATOR
PSA nitrogen generation adopts carbon molecular sieve as adsorbent whose capacity of adsorbing oxygen is larger than adsorbing nitrogen. The two adsorbers (a&b) alternately adsorbing and regenerating to separate oxygen from nitrogen in air to obtain purified
nitrogen by Auto-operated valves controlled by PLC.
nitrogen by Auto-operated valves controlled by PLC.
LIQUID OXYGEN & NITROGEN GENERATOR
Our medium size oxygen/nitrogen plants are designed and manufactured with the latest cryogenic air separation technology, which is trusted as the most efficient technology for high rate of gas generation with high purity. We have world-class engineering expertise enabling us to build industrial gas systems in compliance with internationally approved manufacturing and designing standards.
Membrane Nitrogen generator
Membrane separation nitrogen production technology is currently one of the most advanced room temperature air separation technologies in the world. The principle is to use the difference in the permeability of each component gas in the air through the separation membrane to achieve the purpose of nitrogen and oxygen separation
VPSA OXYGEN GENERATOR
PSA oxygen generator uses zeolite molecular sieve as the adsorbent, and uses the principle of pressure adsorption and decompression desorption to adsorb and release oxygen from the air, thereby separating oxygen from the automatic equipment. N2 molecules have a faster diffusion rate in the micropores of zeolite molecular sieve, and O2 molecules have a slower diffusion rate.
Company Profile
Hangzhou NuZhuo Technology Co., Ltd. is located in the beautiful Fuchun River bank, the hometown of Sun Quan,the Emperor of The Eastern Wu, located in the outskirts of Hangzhou Tonglu Jiangnan New Area, between Hangzhou West Lake and national scenic spots Qiandao Lake, Yaolin Fairyland, Hangzhou New Expressway Fengchuan exit is only 1.5 kilometers away from the company, traffic is very convenient.
Hangzhou NuZhuo Technology Co., Ltd. is a professional manufacturer of cryogenic air separation, VPSA oxygen production device, compressed air purification device, PSA nitrogen production, oxygen production device, nitrogen purification device, membrane separation nitrogen production and oxygen production device, electric. Pneumatic control valve. Temperature control valve. Cut off valve
production enterprises.The company has more than 14000 square meters of modern standard workshop, and advanced product testing equipment.Company always adhere to the "honesty, cooperation, win-win" business philosophy, the development of science and technology, diversified, large-scale road, to the industrialization of high and new technology development, the enterprise has passed ISO9001 quality system certification, and won the "contracts and keep promise unit", the company is listed as one of high and new technology industry in zhejiang province key enterprises of science and technology innovation.
Hangzhou NuZhuo Technology Co., Ltd. is a professional manufacturer of cryogenic air separation, VPSA oxygen production device, compressed air purification device, PSA nitrogen production, oxygen production device, nitrogen purification device, membrane separation nitrogen production and oxygen production device, electric. Pneumatic control valve. Temperature control valve. Cut off valve
production enterprises.The company has more than 14000 square meters of modern standard workshop, and advanced product testing equipment.Company always adhere to the "honesty, cooperation, win-win" business philosophy, the development of science and technology, diversified, large-scale road, to the industrialization of high and new technology development, the enterprise has passed ISO9001 quality system certification, and won the "contracts and keep promise unit", the company is listed as one of high and new technology industry in zhejiang province key enterprises of science and technology innovation.
Packing & Delivery
FAQ
Q1: Are you a trading company or manufacturer?
A: We are a manufacturer.
Q2: What is your term of payment?
A: T/T 30% in advance and T/T 70% balance paid before shipment.
Q3 How long is your delivery time?
A: About 30 days.
Q4: What is your product quality assurance policy?
A: We offer a warranty period of 1 year or 1000 running hours whichever
comes first.
Q5: Do you offer OEM/ODM service?
A: Yes.
Q6: Do you have ATS system?
A: Yes, it is optional.
A: We are a manufacturer.
Q2: What is your term of payment?
A: T/T 30% in advance and T/T 70% balance paid before shipment.
Q3 How long is your delivery time?
A: About 30 days.
Q4: What is your product quality assurance policy?
A: We offer a warranty period of 1 year or 1000 running hours whichever
comes first.
Q5: Do you offer OEM/ODM service?
A: Yes.
Q6: Do you have ATS system?
A: Yes, it is optional.
