Сделано в Китае дюймов Размер: 10x18x5 5 мм одинарные миниатюрный упорный шариковый подшипник F10-18
- Категория: Thrust Ball Bearings >>>
- Поставщик: Shandong,Hanke,Bearing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.95 $* | 0.25 $* |
| Aug-19-2025 | 0.9 $* | 0.32 $* |
| Jul-19-2025 | 0.21 $* | 0.3 $* |
| Jun-19-2025 | 0.91 $* | 0.62 $* |
| May-19-2025 | 0.46 $* | 0.0 $* |
| Apr-19-2025 | 0.85 $* | 0.12 $* |
| Mar-19-2025 | 0.36 $* | 0.17 $* |
| Feb-19-2025 | 0.77 $* | 0.37 $* |
| Jan-19-2025 | 0.31 $* | 0.93 $* |
Характеристики
China made inch size 10x18x5.5mm single direction miniature thrust ball bearing F10-18 F10-18M bearing
PRODUCT DESCRIPTION
* Thrust ball bearings are designed to handle axial loads only.
* Thrust ball bearings consist of ball, retainer and both shaft and housing washers which contain grooves for the ball.
* The double Direction Thrust ball bearings can support bi-directional loads.
* The bearings with spherical housing washer can prevent static misalignment.
* Thrust ball bearings consist of ball, retainer and both shaft and housing washers which contain grooves for the ball.
* The double Direction Thrust ball bearings can support bi-directional loads.
* The bearings with spherical housing washer can prevent static misalignment.
* Thrust ball bearings consist of ball, retainer, both shaft and housing washers which contain grooves for the balls, and can be
subject to axial load only.
* Since introduction of polyamide cages the level of noise substantially improved.
subject to axial load only.
* Since introduction of polyamide cages the level of noise substantially improved.
SPECIFICAIONS
NO. | Item | Data |
1 | Bearing Number | F10-18 bearing |
2 | Inner diameter | 10mm |
3 | Outer diameter | 18mm |
4 | Width | 5.5mm |
5 | Weight | 0.0061kg |
6 | Dynamic load rating | 800N |
7 | Static load rating | 707N |
8 | Limiting speed | 14000 r/min |
9 | Number of balls | 9 |
10 | Ball size | 0.0937 inch |
FEATURES
1. The design of Thrust Ball Bearing may not be subjected to any radial load.
2. Thrust Ball Bearings are not suitable for high-speed rotation since lubricant is expelled by centrifugal force.
3. When used on a horizontal shaft, a minimum axial load must be applied.
Care must be taken in handling to prevent damage to the separable rings and ball assembly.
2. Thrust Ball Bearings are not suitable for high-speed rotation since lubricant is expelled by centrifugal force.
3. When used on a horizontal shaft, a minimum axial load must be applied.
Care must be taken in handling to prevent damage to the separable rings and ball assembly.
