Недорогая заводская цена Высококачественная машина для прокладки

Performance Characteristics:

1.With its multi-functional design, the machine can achieve precise slipform paving for various applications such as road drains, spillways, kerbs, shoulders, concrete fences, and irrigation channels for agricultural water conservancy, by swapping out various molds and precisely adjusting and controlling the vehicle's status.

2.Equipped with three crawler tracks, hydraulically independent drive, proportionally controlled dual-speed motors, and planetary gear reducers, the paving speed is controlled in a closed loop with PID adjustment, ensuring stability during low-speed paving and improving the quality of slipform paving. The front crawler steering device is equipped with a displacement sensor for precise steering.

3.The engine is powerful and meets the national IV emission standard. The hydraulic system adopts load-sensitive variable control, supplying oil based on the actual load size and speed, resulting in low fuel consumption and being environmentally friendly.

4.The operator's console features a user-friendly design with an intuitive human-machine interface control screen and clear graphical recognition symbols, making the paving machine easy and effortless to operate. It is equipped with an Internet of Things platform, including a construction management and monitoring system, and an optional remote control device.

5.The steering and lifting mechanisms utilize hydraulic proportional control, and are equipped with two longitudinal slope sensors, one steering sensor, and one inclination sensor. The sensors communicate with the controller via a CAN bus, improving the equipment's response speed and stability, ensuring precise linear control, and enabling stacked paving.

6.Based on the working conditions, it can achieve paving on the right side or central placement. The mold fixing device adopts hydraulic horizontal and vertical dual-directional adjustment, allowing for rapid replacement of various molds.

7.The auger feeding device's angle and telescopic length can be adjusted hydraulically, providing convenient operation and adaptability to various working conditions. With ample storage space, it can achieve secondary mixing of cement concrete.

8.The overall machine structure is designed to be compact, meeting the requirements for containerized transportation.

Product details
