Б/у машина для изготовления винтов из стали
US $1000-$2000
Самый продаваемый станок для прокатки резьбы-это гидравлический
- Категория: Thread Rolling Machines >>>
- Поставщик: Xingtai,Qiji,Machinery,Manufacturing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 4820.9 $* | 5061.96 $* |
| Aug-16-2025 | 4779.9 $* | 5018.32 $* |
| Jul-16-2025 | 4010.44 $* | 4211.50 $* |
| Jun-16-2025 | 4698.40 $* | 4933.23 $* |
| May-16-2025 | 4091.73 $* | 4296.68 $* |
| Apr-16-2025 | 4617.25 $* | 4848.62 $* |
| Mar-16-2025 | 4577.72 $* | 4806.0 $* |
| Feb-16-2025 | 4536.10 $* | 4763.57 $* |
| Jan-16-2025 | 4496.12 $* | 4721.91 $* |
Характеристики
Product Description
Specification
Product name | QJ-80 |
Maximum processing diameter | 42mm |
Maximum processing pitch | 6mm |
Maximum rolling pressure | 150kn |
Spindle tilt angle | ±5° |
Spindle speed | 39，49，66，82r/min exchange gear |
Rolling wheel outer diameter | 120-170mm |
the inside diameter of | 54mm |
Spindle power | 5.5kw |
Hydraulic power | 2.2kw |
Cooling power | 125w |
Dimensions | 1600*1400*1200mm |
weight | 1800kg+50kg |
Packing & Delivery
Lubrication system
Electronic lubrication, automatic setting, automatic refueling
Stroke adjustment
Easy to adjust, strong stability
Synchronous drive shaft
Adjustable mounting bracket
Can be installed at any angle
The rolling wheel bracket adopts double-disk bearings, heat treatment in the air, high hardness and durable
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
