Промышленная вакуумная сушильная машина из нержавеющей

Описание и отзывы

Трекер стоимости

Характеристики

Specifications

tea drying and sterilization machine
1.fast drying time,2~6min
2.saving energy
3.best effect
4.cover less area

green tea microwave drying and sterilization machine







1.fast drying time,2~6min
2.saving energy
3.best effect
4.cover less area



1.Application:



Mainly used in:Green tea,oolong tea,black tea,health tea etc .Kill out processing,the passivation of polyphenol oxidase activity,evaporate partial water,volatile grass smell,soften the tissue.Can keep the content of amino acids,vitamin C of the green tea after processing,the color more green,shape stretched naturally ,beautiful and improve the quality .



2.Features:



1. Good efficiency of killing out and drying,short processing time of drying tea (1/8time of roasted );



2. Uniform heating,simple operation,easy to use,can work continuously;



3. The microwave processing of tea,also have a sterilization antifungal function .While drying tea,also can sterilize and kill insects and larvae.



3.Technical Parameters:



Model	Rated input power(KVA)	Microwave output power(KW)	Expected dehydration(kg/h)	Expected sterilization capacity(kg/h)	Dimension L*W*H(mm)
JN-12	18kw	12kw	12~17	150~20	7290*840*1750
JN-15	21kw	15kw	15~21	200~250	8420*840*1750
JN-18	26KW	18KW	18~22	230~280	8420*840*1750
JN-20	28kw	20kw	20~28	280~350	9550*840*1750
JN-25	36kw	25kw	25~35	350~400	9550*840*1750
JN-30	42kw	30kw	30~42	400~480	10680*840*1750
JN-35	49KW	35KW	35~45	480~550	10680*840*1750
JN-40	56kw	40kw	40~48	550~650	10680*1410*1750
JN-45	63KW	45KW	45~52	600~700	11810*1410*1750
JN-50	70kw	50kw	50~60	700~800	11810*1410*1750
JN-60	84kw	60kw	60~84	850~1000	12940*1410*1750
JN-70	98kw	70kw	70~~98	1000~1100	14070*1410*1750
JN-75	105kw	75kw	75~105	1100~1200	15200*1410*1750
JN-80	112kw	80kw	80~112	1200~1400	15200*1600*1750
JN-100	140kw	100kw	100~140	1400~1600	15200*1665*1750
JN-120	168kw	120kw	120~168	1600~2000	17460*1665*1750
JN-150	210kw	150kw	150~210	2000~2500	20850*1750*1750
NOTE: We can specially design the equipment according to your products’ features.
