22 кВт 30 л.с. отличный дешевый китайский
- Категория: Tractors >>>
- Поставщик: SHANDONG,MSANG,MACHINERY,CO.,LTD.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 5236.98 $* | 5498.63 $* |
| Aug-16-2025 | 5192.54 $* | 5452.40 $* |
| Jul-16-2025 | 4356.17 $* | 4574.57 $* |
| Jun-16-2025 | 5104.25 $* | 5359.94 $* |
| May-16-2025 | 4444.1 $* | 4666.71 $* |
| Apr-16-2025 | 5016.92 $* | 5267.60 $* |
| Mar-16-2025 | 4972.5 $* | 5221.72 $* |
| Feb-16-2025 | 4928.63 $* | 5174.3 $* |
| Jan-16-2025 | 4884.43 $* | 5128.10 $* |
Характеристики
Specification
This series tractor is a versatile, high horsepower agricultural tractors. The model has compact structure, convenient operation,
flexible steering, traction, versatile and easy maintenance characteristics. The series use TD chassis, four wheel drive, 16F+8R
shuttle shifts gear box, hydraulic steering, double stage clutch and the 3-point linkage is adjustable by floating way.
The series can choose to equip the roll bar, hydraulic multi-valves, heater and AC cabin
Sales territory: regions like Europe, South America and Australia, Africa and other areas
Matched machines and tools: ploughing tools like disc plough, disc harrow, rotary tiller and cultivator. Optional tools like front
loader, backhoe, trailer, mower, rake, spraying machine
flexible steering, traction, versatile and easy maintenance characteristics. The series use TD chassis, four wheel drive, 16F+8R
shuttle shifts gear box, hydraulic steering, double stage clutch and the 3-point linkage is adjustable by floating way.
The series can choose to equip the roll bar, hydraulic multi-valves, heater and AC cabin
Sales territory: regions like Europe, South America and Australia, Africa and other areas
Matched machines and tools: ploughing tools like disc plough, disc harrow, rotary tiller and cultivator. Optional tools like front
loader, backhoe, trailer, mower, rake, spraying machine
Product Description
Model | MG304 tractor | Type | 4X4 wheeled type |
Main dimensions | Number of Bores | 2/3 | |
W XD X H (mm) | 2860X1260X1200 | Bore dia. X stroke (mm) | 102X105 |
Wheel base (mm) | 1520 | Combustion chamber | direct injection |
Front wheel (mm) | 1070 | Rated Power (kw) | 22.06 |
Rear wheel (mm) | 1000 | Fuel consumption (g/kw.h) | ≤248.9g/kw.h |
Min. ground clearance (mm) | 220 | Engine oil consumption (g/kw.h) | ≤2.04g/kw.h |
Min. turning circle radius (m) | Front tyre size | 6.00-12 | |
When one-side braking | 2.4±0.2 | Rear tyre size | 9.50-16 |
Differential | closed, 2 planetary gear | Type | Vertical 4 stroke, water cooled |
Differential lock | Jaw type | Max. lifting capacity (kN) | 4.96 |
Diesel Engine | WEICHAI ENGINE | Gear shifts | (4+1)x2 |
