Высокоэффективная анкерная буровая установка гусеничного типа для почвы
- Категория: Mining Machinery >>>
- Поставщик: Jining,Hengwang,Mining,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.43 $* | 0.79 $* |
| Aug-18-2025 | 0.74 $* | 0.96 $* |
| Jul-18-2025 | 0.53 $* | 0.88 $* |
| Jun-18-2025 | 0.44 $* | 0.74 $* |
| May-18-2025 | 0.25 $* | 0.77 $* |
| Apr-18-2025 | 0.95 $* | 0.66 $* |
| Mar-18-2025 | 0.42 $* | 0.7 $* |
| Feb-18-2025 | 0.48 $* | 0.86 $* |
| Jan-18-2025 | 0.3 $* | 0.52 $* |
Характеристики
Product Description
High efficiency crawler type anchor drilling rig soil nail drilling rig micropile drilling rig
HW-135D HW-150D Anchor Drilling Rig
Drill diameter: 150-250mm
Drill depth (m): 100-140-170m
Drilling angle: 0-90°
Drill depth (m): 100-140-170m
Drilling angle: 0-90°
* Site Instrcution and Installation
* Professtional After-Sales Team
* CE, BV, TUV, ISO
Technical Parameters
Anchor drill machine parameter | ||||||
Model | HW-150S | HW-150D | HW-150F | |||
Drill diameter (mm) | 100-210 | 150-250 | 150-250 | |||
Drill depth (m) | 60-100 | 130-170 | 180-220 | |||
Pipe diameter (mm) | 73 89/102/114 | 73/89/102/ 114 | 73/ 89/ 102/ 114 | |||
Drilling angle (' ) | -10-90 | 0-90 | 0-90 | |||
Gyrator Output rotary speed (r/min) | 16-105 | 10-170 | 40-170 | |||
Gyrator Output torque (N. m) | 4200 | 7500 | 11000 | |||
Gyrator Stroke (mm) | 1800 | 3400 | 3400 | |||
Gyrator lift (kN) | 65 | 70 | 80 | |||
Gyrator lifting speed (m/min) | 0-5adjustable、7、23、30 | 0-5 adju stable /7/23/30 | 0-1.4 djustable、16/18 | |||
Gyrator pressure (kN) | 33 | 36 | 40 | |||
Gyrator Feeding speed (m/min) | 0-10 adjustable/14/46/59 | 0-10 adjustable / 14/46/59 | 0-2.8adjustable、32/35 | |||
Driving mode | Crawler option | Crawler | Crawler | |||
Travel speed (km/h) | 15 | 20 | 22 | |||
Diesel Input power (kW) | 39 | 96 | 117 | |||
Motor Input power (kW) | 30+1.5 | 55+18.5 | 55+30+2.2 | |||
Dimension (L*W*H) mm | 3000X1800X1500 | 5400x2100x2000 | 6200X2100X2000 | |||
Weight (kg) | 1300 | 6500 | 9200 | |||
High efficiency crawler type anchor drilling rig soil nail drilling rig micropile drilling rig
Main feature
1. Full hydraulic control, Operation is convenient and flexble, easy shifting, good maneuverability, saving time and labor.
2. High output torque, rotary center lower than similar products, greatly improving the drilling machine's drilling stability.
3. can meet three-wing drill drilling, DTH hammer drilling, casing complex drilling, single/double/triple rotary spray, fixed spray, swing spray and so on.
3. can meet three-wing drill drilling, DTH hammer drilling, casing complex drilling, single/double/triple rotary spray, fixed spray, swing spray and so on.
High efficiency crawler type anchor drilling rig soil nail drilling rig micropile drilling rig
