JL800-F гравировальный станок с ЧПУ ремесел скульптура хорошее соотношение цены и

JL800-F гравировальный станок с ЧПУ ремесел скульптура хорошее соотношение цены и

Категория: Boxing Machines >>>
Поставщик: Wenzhou,Xinguang,International,Trade,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.28 $*	0.32 $*
Aug-17-2025	0.18 $*	0.22 $*
Jul-17-2025	0.78 $*	0.67 $*
Jun-17-2025	0.89 $*	0.82 $*
May-17-2025	0.9 $*	0.88 $*
Apr-17-2025	0.76 $*	0.89 $*
Mar-17-2025	0.98 $*	0.80 $*
Feb-17-2025	0.57 $*	0.79 $*
Jan-17-2025	0.70 $*	0.37 $*

Характеристики

Our Services

As distributor, our most advantage is competitive price and effective aftersale service.

we offer on-the-spot serivice within 24 hours worldwide

Your one stop solution for Printing&Packaging

Engraving machine machine

Product Description

Function and Characteristics

The three-axis adopts a fully sealed and dust-proof method, and dust is not easy to enter the gear and ball screw;
The circuit pipeline is completely separated from the cutting environment, which can protect the circuit for a longer time and make the machine used for longer life.
Industrial control system configuration and operation are simple and stable

Main technical Parameter

XYZ axis working stroke	800x800x1 10mm	X/Y/Z motion positioning accuracy	0.005mm
Table size	800x800mm	X/Y/Z repeat positloning precision	0.008mm
Flatness of table	0.025/300mm	Z-axis space height	130~ 180mm
XY perpendicularity	0.015/300mm	Drive System	AC servo
Spindle power	2.2KW	CNC system	Weihong/Taiwan xindai
Spindle Rotating speed	5000~ 24000rpm	X/Y/Z axis moving speed	15x15x10m/min
Maximum work load	350kg	Maximum cutting feed speed	6m/min
Voltage	Single- phase 220V/50Hzt 10% (can be equipped remotely)
machine weight:	2000kg	Machine dimensions:	1750x1900x1750mm

Carton GS and size:
Model	650GS	800GS	1100GS
A	650-100	800-100	1100-100
B	500-60	800-60	800-60
Size of two-sides glue box and folded box
Model	650GS	800GS	1100GS
A	500-100	800-150	1100-250
B	400-60	800-60	800-60
H	150-20	150-20	150-20
Size of bottom-locked carton and folding carton
Model	650GS	800GS	1100GS
A	650-146	800-146	1100-250
B	450-60	700-60	1700-80
H	180-20	180-20	100-25
Size of 4 corners box and folding box
Model	650GS	800GS	1100GS
A	500-120	800-120	1100-120
B	400-120	800-130	800-130
C	150-20	150-30	150-30
Size of 6 folds box and folding box
Model	650GS	800GS	1100GS
A	500-120	800-120	1100-250
B	400-100	800-130	800-130
C	150-30	150-30	150-30
