Пресс-фильтр для обезвоживания осадка высокого

Пресс-фильтр для обезвоживания осадка высокого

Категория: Filter Press Equipment >>>
Поставщик: Woking,Environmental,Technology,Co.,Ltd.

Цена:8 000,00 $ - 12 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	9520.34 $*	9996.73 $*
Aug-20-2025	9440.38 $*	9912.75 $*
Jul-20-2025	7920.80 $*	8316.69 $*
Jun-20-2025	9280.99 $*	9744.55 $*
May-20-2025	8080.48 $*	8484.36 $*
Apr-20-2025	9120.40 $*	9576.22 $*
Mar-20-2025	9040.71 $*	9492.25 $*
Feb-20-2025	8960.64 $*	9408.20 $*
Jan-20-2025	8880.82 $*	9324.58 $*

Характеристики

Product Description

Applications

Filter press is suitable for almost all types of slurry, such as: ceramics industry, stone industry, glass industry,
mining & minerals industry, coal washing, sand washing, pull&paper industry, food industry, chemical & pharmacy industry,
electroplating industry, textile& dyeing, leather industry, municipal slurry etc.

Feature

1、High efficiency diaphragm filter adopts low pressure filtration, secondary high pressure press, greatly shorten the entire filtration cycle, improve productivity;
2、The maximum filtration pressure can reach 2.5Mp, greatly reduce the moisture content, save drying cost, improve the yield;
3、Diaphragm pressing function, in a very short time to complete this process, saving power consumption;
4、Diaphragm filter plate has anti-fatigue, anti-aging, good sealing performance, anti corrosion ability, etc., is basically suitable for all solid-liquid separation operations;
5、Can be equipped with PLC program control and intelligent man-machine interface control, reduce manpower consumption.

Optional facility

Specification

Filter area(㎡)	Tickness of filter plate(mm)	QTY of filter plate	Totd volume(L)	Press pressure(Mpa)	External Dimensions(LWH)(mm)	Machine weight(KG)
50	65/60	50	750	0.5-1.6	4785X1100X1600	3150
150	78/72	58	3220	0.5-1.6	8190X1930X1620	13620
200	78/72	78	4050	0.5-1.6	9400X1930X1620	15320
250	78/72	96	5020	0.5-1.6	10770X1930X1620	17020
400	85/80	116	8070	0.5-1.6	13270X2400X1880	34900
