Машина для изготовления пластиковых чехлов телефона машина литья под давлением пластиковая
- Категория: Injection Molding Machine >>>
- Поставщик: Ningbo,Hoy,Machinery,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 30976.72 $* | 32525.0 $* |
| Aug-18-2025 | 30715.64 $* | 32251.3 $* |
| Jul-18-2025 | 25770.3 $* | 27059.99 $* |
| Jun-18-2025 | 30195.64 $* | 31705.2 $* |
| May-18-2025 | 26290.24 $* | 27605.89 $* |
| Apr-18-2025 | 29674.33 $* | 31158.70 $* |
| Mar-18-2025 | 29414.2 $* | 30885.48 $* |
| Feb-18-2025 | 29154.37 $* | 30612.31 $* |
| Jan-18-2025 | 28893.91 $* | 30338.69 $* |
Характеристики
1.Technology parameters:
DESCROPTION | UNIT | MODEL: M260 | ||
| A | B | C | |
INJECTION UNIT | ||||
Screw Diameter | mm | 50 | 55 | 60 |
Injection Pressure | kg/cm2 | 196 | 162 | 136 |
Shot Volume (Theoretical) | cm3 | 540 | 653 | 778 |
Shot Weight (PS) | g | 491 | 595 | 708 |
oz | 17.31 | 20.99 | 24.97 | |
Injection Rate | cm3/s | 218 | 263 | 314 |
Plasticizing Capacity | kg/hr | 32 | 43 | 53 |
Screw Speed | rpm | 210 | ||
CLAMPING UNIT | ||||
Clamp Force | kn | 2600 | ||
Space Between Tie Bars (W*H) | mm | 570X520 | ||
Max. Mold Height | mm | 585 | ||
Min. Mold Height | mm | 230 | ||
Mold Locating Ring Diameter | mm | 125 | ||
Ejector Stroke | mm | 160 | ||
Ejector Force | kn | 80 | ||
OTHERS | ||||
Motor Power | kw | 25(80*2500) | ||
Heater Power | kw | 12 | ||
Oil Tank Capacity | l | 260 | ||
Machine Dimension (LxWxH) | m*m*m | 5.6X1.4X2.2 | ||
Machine Weight | Ton | 8.0 | ||
2.The famous and high-performance components
3. Application Industry
4. Innovation Technology
