Гидравлический Гараж портативный автомобильный подвижный средний подъем гидравлический ножничный
- Категория: Car Lifts >>>
- Поставщик: Zhongcan,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 888.41 $* | 906.52 $* |
| Jul-16-2025 | 720.50 $* | 734.91 $* |
| Jun-16-2025 | 874.96 $* | 891.32 $* |
| May-16-2025 | 867.79 $* | 884.51 $* |
| Apr-16-2025 | 692.32 $* | 706.71 $* |
| Mar-16-2025 | 853.69 $* | 870.63 $* |
| Feb-16-2025 | 846.44 $* | 863.86 $* |
| Jan-16-2025 | 839.31 $* | 856.26 $* |
Характеристики
Products Description
The executive part of the scissor lift adopts the form of scissor stacking rod, and the electric drive mechanical transmission structure is widely used in the maintenance of large vehicles.
The lifting speed of the scissor lift is moderate and does not occupy the position of the car pit.It is undoubtedly the best choice for the repair field of some models with relatively fixed and high work intensity (such as in buses).
And because of its simple structure and good synchronization, it is generally used as a platform for four-wheel alignment.
Details Images
LOAD CAPACITY | PLATFORM SIZE | TRAVEL HEIGHT | MIN.HEIGHT | POWER |
3000kg | 5000x2500mm | 3000mm | 650mm | 5.5KW |
3000kg | 5000x2500mm | 4000mm | 800mm | 5.5KW |
3000kg | 5000x2500mm | 6000mm | 800mm | 7.5KW |
5000kg | 6500x2600mm | 3000mm | 680mm | 7.5KW |
5000kg | 6500x2600mm | 4000mm | 680mm | 7.5KW |
Lifting capacity | 2700KG /3000kg | ||||||
Lifting height | 1000MM (39.4") | ||||||
Min height | 110MM(4.3") | ||||||
Lifting time | 30S | ||||||
Overall length of platform | 1400MM-1940MM (55.1-76.4") | ||||||
width of platform | 520MM (20.5") | ||||||
Overall width of platform | 1840MM (72.4") | ||||||
Width between platform | 800MM (31.5") | ||||||
Motor power | 2.2KW-380V/220V | ||||||
Air supply | 0.6-0.8MPA | ||||||
N.W/GW | 550KG (1212LBS)/580KG(1279LBS) | ||||||
hydraulic cylinders for
powerful lifting.
2.All joints are equipped with
DIN grease nipples for
prefect servicing.
2.Lockable access ramps for lifting longer vehicles.
2.Movable pump station,electronic control pneumatic unlock,mobile flexible and convenient.
3.Power unit with pure copper core motor international famous brands.
Zhongcan Machinery Co., Ltd. is a modern technology-based manufacturing enterprise specializing in the design, research and development, production, sales and after-sales service of lifting equipment. There are six series of more than fifty varieties. The main products are Car lift, wheelchair lifts, home lifts, self-propelled lifts, fixed docking lamps, mobile docking lamps,Cargo lift, aluminum alloy lifts, etc.
